SMC Networks AW20 Series Operational Manual page 47

13-2. Standard (with square embedded type pressure gauge or digital pressure switch)
Panel mounting dimensions
Plate thickness
AW20-D, AW30-D: Max．3.5
AW40-D
Dimensions
Model
P A
1
AW20-D 1/8, 1/4 40
AW30-D 1/4, 3/8 53
AW40-D 1/4, 3/8, 1/2 70
3/4 75
AW40-06-D
AW60-D 3/4, 1 95
Model Bracket mount
Ｍ Ｎ
Q
AW20-D
30 34 43.9
AW30-D 41 40 46
AW40-D 50 54 54
50 54 55.5
AW40-06-D
AW60-D 70 75 66
The dimension C is the length when the filter regulator knob is unlocked.
: Max．5
Standard specifications
B C D E
87.6 71.8 26 -
115.3 86.5 31.5 30
147.1 91.5 40.5 38.4
149.1 93 40.5 38.4
234.1 155 50 38.4
Optional specifications
Ｓ Ｔ
R U V
5.4 15.4 55 2.3 29.7
6.5 8 53 2.3 31.3
8.5 10.5 70 2.3 35.5
8.5 10.5 70 2.3 35.5
11 22 113 3.2 -
Square embedded type
pressure gauge
Center of piping
(Port size)
Square embedded ty pe
pressure gauge
Ｈ
F G K
□28
M28×1 40 5
□28
M38×1.5 55 3.5
□28
M42×1.5 80 0
□28
M42×1.5 80 0
□28
M62×1.5 30 0
With
Panel mount auto
drain
W Y Z B
28.5 14 6 104.9
38.5 19 7 157
42.5 21 7 186.9
42.5 21 7 188.9
- - - 273.9
-46-
Digital pressure switch
Center of piping
Optional specifications
Digital pressure
switch
Ｈ
J J
□27.8
27 37.5
□27.8
32.5 43
□27.8
41.5 52
□27.8
41.5 52
□27.8
51 61.5
Semi-standard specifications
PC/ PA bowl Metal bowl
With barb With drain With drain With drain
f itting guide cock
B B B
- 91.4 87.4
123.9 122.2 117.8 122.3
155.6 153.9 149.5
157.6 155.9 151.5
242.6 240.9 236.5
Metal bowl with
level gauge
With drain With drain
guide cock guide
B B B
93.9 - -
137.8 142.3
154 169.5 174
156 171.5 176
241 256.5 261
