WP-8000-CE7 Series
User Manual
V1.0.2, September 2020
WP-8121-CE7/WP-8421-CE7/WP-8821-CE7
Written by Sean Hsu
Edited by Anna Huang

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WP-8000-CE7 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP DAS USA WP-8000-CE7 Series

Summary of Contents for ICP DAS USA WP-8000-CE7 Series

  • Page 1 WP-8000-CE7 Series User Manual V1.0.2, September 2020 WP-8121-CE7/WP-8421-CE7/WP-8821-CE7 Written by Sean Hsu Edited by Anna Huang...
  • Page 2 If you have any problem, please feel free to contact us. You can count on us for quick response. Email: service@icpdas.com WP-8000-CE7 Series User Manual, version 1.0.2 Page: 2 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 3: Table Of Contents

    Remote_Display ..........................54 3.6. SendToCOM ............................ 55 3.7. RegEdit ............................56 3.8. ISQLW35 ............................57 3.9. INotepad ............................58 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 3 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 4 C# Demos for PAC Expansion I/O ..................117 6.2.3. Visual C++ Demos for PAC Expansion I/O ................119 WP-8000-CE7 UPDATES ....................121 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 4 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 5 Star Type RS-485 Network ....................... 154 F.4. Random RS-485 Network ......................156 F.5. Master/Slaves Settings ......................157 Revision History ..........................162 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 5 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 6: Introduction

    Using Windows CE 7.0 in the WP-8000-CE7 gives it the ability to run PC-based Control software such as Visual Basic.NET, Visual C#, Visual C++, SCADA software, Soft PLC and etc. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 6...

  • Page 7: Features

     .NET Compact Framework 3.5  Remote Display  Rich Software Solution – SDK for Microsoft Visual Studio 2008 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 7 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 8: Specifications

    Internal communication with the high profile I-87K series COM 0 modules in slots COM 1 RS-232 (RxD, TxD and GND); Non-isolation WP-8000-CE7 Series User Manual, version 1.0.2 Page: 8 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 9 7.3 W (0.3 A @ 24 9.1 W (0.38 A @ 24 9.6 W (0.4 A @ 24 Consumption WP-8000-CE7 Series User Manual, version 1.0.2 Page: 9 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 10: Overview

    1.3. Overview Here is an overview of the components and its descriptions. WP-8121-CE7 WP-8421-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 10 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 11 Rotary Switch is an operating mode selector. The WP-8000-CE7 has several operating modes, for more detailed information about these operating mode, please refer to “2.4 Configuring the Boot Mode” WP-8000-CE7 Series User Manual, version 1.0.2 Page: 11 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 12 The WP-8000-CE7 has a relay output that can be used to control a light, siren, or other low voltage device when an alarm occurs. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 12 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 13 Communication Ports The WP-8000-CE7 Series modules are equipped with several interfaces and peripherals that can be integrated with external systems. ● VGA Port The VGA connector is a 3-row 15-pin connector that can be used to connect a monitor at a variety of supported VGA resolutions. and the output resolution covers, 800 x 600, 1024 x768.
  • Page 14 Baud Rate: 115200, 57600, 38400, 19200, 9600, 4800, 2400, 1200 bps Data Bits: 7, 8 Parity: None, Even, Odd Stop Bits: 1 FIFO: 64 byte WP-8000-CE7 Series User Manual, version 1.0.2 Page: 14 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 15 Data Bits: 5, 6, 7, 8 Parity: None, Even, Odd, Mark (Always 1), Space (Always 0) Stop Bits: 1, 2 FIFO: 128 bytes WP-8000-CE7 Series User Manual, version 1.0.2 Page: 15 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 16 The DIP switch can be used to set the Module ID to a number from 0 to 255. Do not use Module ID 0 for communication. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 16 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 17: Dimensions

    The height dimension is the same for all WP-8000-CE7. The width depending on your choose of I/O expansion slots. All dimensions are in millimeters. WP-8121-CE7 WP-8421-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 17 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 18 WP-8821-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 18 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 19: Companion Cd

    System_Disk The tools and drivers related to System_Disk that install on WP-8x21-CE7. Update The installation packages related to WP-8x21-CE7. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 19 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 20: Getting Started

    A microSD card and a micro SD/SD adapter Quick Start Guide Software Utility CD Screw Driver (1C016) 2.4 mm WP-8000-CE7 Series User Manual, version 1.0.2 Page: 20 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 21: Mounting The Wp-8000-Ce7

    There must be a minimum clearance of 50mm between the WP-8000-CE7 and the top and bottom side of the enclosure panel. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 21 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 22 Step 2: Tilt the module toward DIN rail until it snaps securely to DIN rail Step 3: Push up retaining clips WP-8000-CE7 Series User Manual, version 1.0.2 Page: 22 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 23 There must be a single-point ground (i.e. copper bus bar) for all devices in the enclosure that require an earth ground. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 23 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 24: Deploying A Basic Wp-8000-Ce7 System

    If one power source fails, the other source takes over automatically. Redundant power inputs help assure non-stop operation of the WP-8000-CE7. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 24 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 25 Step 3: Connect the monitor to the VGA port Step 4: Connect to PC or the laptop to the LAN port via an Ethernet switch WP-8000-CE7 Series User Manual, version 1.0.2 Page: 25 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 26: Installing The I/O Modules

    It is recommended that the power to the WP-8000-CE7 is switched off when wring the I/O module which are plugging in the WP-8000-CE7 slots. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 26 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 27 For example, Pin Assignments and Wiring connections for the I-87054W module are as follows: http://www.icpdas.com/en/product/I-87054-G Insert the terminal block Attach field wiring WP-8000-CE7 Series User Manual, version 1.0.2 Page: 27 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 28: Configuring The Boot Mode

    Normal mode is the default mode of operation and the one you will use most of the time. Use this mode for more tasks and configurations. Programs also are executed in this mode. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 28 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 29 When WP-8000-CE7 is boot with one of these positions, it is boot at normal mode. User’s application can check the position of the rotary switch position to run at different mode. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 29 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 30: Changing The User Interface Language

    WP-8000-CE7 user interface with your native language. Step 1: Click Start menu, point to Settings, click Control Panel, and then click Regional Settings WP-8000-CE7 Series User Manual, version 1.0.2 Page: 30 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 31 Step 3: Double-click the PAC Utility on the desktop, and then reboot the WP-8000-CE7 for changes to take effect WP-8000-CE7 Series User Manual, version 1.0.2 Page: 31 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 32: Using Pac Utility To Manage The Wp-8000-Ce7

    Step 2: Configure IP address (DHCP), FTP Server, Auto Execution files…, etc. Step 3: Reboot the WP-8000-CE7 for changes to take effect WP-8000-CE7 Series User Manual, version 1.0.2 Page: 32 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 33: Using Dcon Utility Pro Configure I/O Modules

    DCON Utility Pro allows users to configure and manage the I/O modules via Ethernet or serial ports (RS-232/RS-485). Step 1: Double-click the DCON_Utility_Pro on the desktop Step 2: Click the button WP-8000-CE7 Series User Manual, version 1.0.2 Page: 33 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 34 For more information on these COM port selections, please refer to the specification of the pin assignments in section 1.3. Overview WP-8000-CE7 Series User Manual, version 1.0.2 Page: 34 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 35 Step 4: Click the button to scan the I/O module Step 5: Click the module name to configure the I/O module WP-8000-CE7 Series User Manual, version 1.0.2 Page: 35 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 36: Tools And Tasks

    CD that was provided with the package or by downloading the latest version from ICP DAS web site. CD:\WinPAC_AM335x\wp-8x2x\System_Disk\Tools\ http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/system_disk/tools/ DCON_Utility_Pro ISQLW35 modbus_master_tool Notepad PAC_Utility RegEdit Remote_Display SendToCOM TaskMgr VCEP WP-8000-CE7 Series User Manual, version 1.0.2 Page: 36 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 37: Pac Utility

    All of these functions will be explained later. Menu bar Property Tab File General Help General2 Display IP Config Network Device Information Auto Execution Rotary Execution WP-8000-CE7 Series User Manual, version 1.0.2 Page: 37 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 38: Menu Bar - File

    Reboot Restarts the WP-8000-CE7 Restore Utility Default Settings Restore the WP-8000-CE7 to default settings. Exit Exits the PAC Utility. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 38 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 39: Menu Bar - Help

    How to use About Displays a dialog box with information about PAC Utility, including the current version and copyright information. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 39 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 40: Property Tab - General

    Any changes made to the WP-8000-CE7 will be saved by clicking the Save and Reboot from File menu. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 40 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 41 Refer to the Appendix A.2. How to configure the service for of system time automatically synchronizing with the internet time server. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 41 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 42: Property Tab - General2

    How to use Specify the name of the USB disk Enter a name in the USB Hard Disk: field WP-8000-CE7 Series User Manual, version 1.0.2 Page: 42 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 43: Property Tab - Display

    Select the desired refresh rate from the Screen refresh rate refresh rate drop-down list, and then click the Apply button. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 43 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 44: Property Tab - Ip Config

    Set the network button. settings Assign an IP address: Select the Assign IP address option, and then click the Apply button. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 44 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 45: Property Tab - Network

    Disable the FTP access: Select the Disable check box in the FTP field, and then click the Apply button. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 45 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 46 Refer to the Appendix C.1 How to add a user account to remote accounts login the WP-8000-CE7 from PC. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 46 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 47 The tab use to How to use Set the SMB server Click the Settings button to set the SMB server path. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 47 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 48: Property Tab - Device Information

    The Device Information tab provides functions to monitor necessary system information of the WP-8000-CE7. The information is the most important note of version control for upgrading system. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 48 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 49: Property Tab - Auto Execution

    Click the Browse button to select the execute file which you want, running at startup and then click the Apply button. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 49 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 50: Property Tab - Rotary Execution

    Click the Browse button to select the execute file in one of the user defined mode which you want, and then click the Apply button. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 50 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 51: Dcon Utility Pro

    Using DCON Utility Pro to Configure I/O Modules For more detailed information on DCON Utility application, please refer to: http://www.icpdas.com/en/product/guide+Software+Utility_Driver+DCON__Utility__Pro WP-8000-CE7 Series User Manual, version 1.0.2 Page: 51 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 52: Taskmgr

    The TaskMgr is a Windows CE application, which provides real time info on all processes and threads including System threads, similar in appearance to the Windows Task Manager. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 52 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 53: Vcep

    LZW scheme to minimize the amount of data transmitted from server to client. For more detailed information on VCEP application, please refer to http://www.icpdas.com/en/product/guide+Software+Applications+VCEP__(Virtual__CE__Pro) WP-8000-CE7 Series User Manual, version 1.0.2 Page: 53 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 54: Remote_Display

    Once a connection is established between the client and server (initiated by the client), the client will periodically send requests for screen updates and send mouse/key click information to the server to simulate. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 54 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 55: Sendtocom

    For more information about these commands for communicating with expansion module, please refer to: CD:\WinPAC\napdos\io_module\87k_high_profile_modules.htm WP-8000-CE7 Series User Manual, version 1.0.2 Page: 55 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 56: Regedit

    For more information, see Registry Settings Management in Deployment. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 56 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 57: Isqlw35

    3.8. ISQLW35 The ISQLW35 is a Windows Embedded Compact 7 functionality that implements SQL Server Compact 3.5 Query. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 57 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 58: Inotepad

    3.9. INotepad The INotepad is a common text-only editor. The resulting files have no format tags or styles. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 58 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 59: Your First Wp-8000-Ce7 Program

    Before writing your first program, ensure that you have the necessary development tool and the corresponding SDKs are installed on your system. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 59 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 60: Preparing The Development Tools And Programming Languages

    2. Visual Studio 2008 update for Windows Embedded Compact 7 http://www.microsoft.com/en-us/download/confirmation.aspx?id=11935 3. Windows Embedded Compact 7 ATL Update for Visual Studio 2008 SP1 http://support.microsoft.com/kb/2468183/en-us WP-8000-CE7 Series User Manual, version 1.0.2 Page: 60 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 61: Installing The Wp-8000-Ce7 Sdk

    Follow the prompts until the installation process is complete. Step 3: Execute the VisualStudioDeviceWindowsEmbeddedCompact7 Follow the prompts until the installation process is complete. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 61 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 62: Setting Up The Global Compiler Settings (For Visual C++)

    The directories can be specified where the compiler will search for include files and libraries. Step 1: Start Visual Studio 2008 Step 2: On the Tools menu, click Options… WP-8000-CE7 Series User Manual, version 1.0.2 Page: 62 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 63 Step 5: Use the buttons in the Options dialog box to add additional include paths The path of “$(VCInstallDir)ce7\include” and “$(VCInstallDir)ce7\atlmfc\include” must be moved to the top of the list. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 63 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 64: First Wp-8000-Ce7 Program In Vb.net

    In this tutorial, we will assume that you have installed WP-8000-CE7 SDK on PC and used the Visual Studio 2008 for application development. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 64 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 65: Create A New Project

    Step 1: Start Visual Studio 2008 Step 2: On the File menu, point to New, and then click Project WP-8000-CE7 Series User Manual, version 1.0.2 Page: 65 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 66 Step 4: In the list of Templates, select Smart Device Project Step 5: Specify a name and a location for the application and then click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 66 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 67 .NET Compact Framework Version 2.0 there is no guarantee that the program will function correctly. Step 8: In the list of templates, select Device Application. Click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 67 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 68: Specify The Path Of The Pac Reference

    ICP DAS web site. CD:\WinPAC_AM335x\WP-8x2x\SDK\PACNET\ http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/sdk/pacnet/ Step 2: On the Project menu, and then click Add Reference… WP-8000-CE7 Series User Manual, version 1.0.2 Page: 68 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 69 Step 3: On the Browse tab and browse to where the PACNET.dll are installed, and then click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 69 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 70: Add The Control To The Form

    Step 1: On the Toolbox panel, drag a Button control onto the form ‘ WP-8000-CE7 Series User Manual, version 1.0.2 Page: 70 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 71 Step 2: On the Properties panel, type Check the SDK version in the Text field WP-8000-CE7 Series User Manual, version 1.0.2 Page: 71 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 72: Add The Event Handling For The Control

    Step 2: Inserting the following code Dim data(30) As Byte PACNET.Sys.GetSDKVersion(data) MessageBox.Show(PACNET.MISC.WideString(data)) Tips & Warnings The “PACNET” of “using PACNET” is case- sensitive. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 72 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 73: Upload The Application To Wp-8000-Ce7

    FTP server. …… …… …… …... Step 1: On the Build menu, and then click Build [Project Name] WP-8000-CE7 Series User Manual, version 1.0.2 Page: 73 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 74 WP-8000-CE7, the corresponding PACNET.dll must be in the same directory as the .exe file. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 74 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 75: Execute The Application On Wp-8000-Ce7

    4.2.6. Execute the application on WP-8000-CE7 After uploading the application to WP-8000-CE7, you can just double-click it on WP-8000-CE7 to execute it. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 75 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 76: First Wp-8000-Ce7 Program In Visual C

    In this tutorial, we will assume that you have installed WP-8000-CE7 SDK on PC and used the Visual Studio 2008 for application development. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 76 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 77: Create A New Project

    Step 1: Start Visual Studio 2008 Step 2: On the File menu, point to New, and then click Project WP-8000-CE7 Series User Manual, version 1.0.2 Page: 77 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 78 Step 4: In the list of Templates, select Smart Device Project Step 5: Specify a name and a location for the application and then click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 78 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 79 .NET Compact Framework Version 2.0 there is no guarantee that the program will function correctly. Step 8: In the list of templates, select Device Application. Click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 79 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 80: Specify The Path Of The Pac Reference

    ICP DAS web site. CD:\WinPAC_AM335x\WP-8x2x\SDK\PACNET\ http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/sdk/pacnet/ Step 2: On the Project menu, and then click Add Reference… WP-8000-CE7 Series User Manual, version 1.0.2 Page: 80 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 81 Step 3: On the Browse tab and browse to where the PACNET.dll are installed, and then click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 81 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 82: Add The Control To The Form

    Step 1: On the Toolbox panel, drag a Button control onto the form WP-8000-CE7 Series User Manual, version 1.0.2 Page: 82 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 83 Step 2: On the Properties panel, type Check the SDK version in the Text field WP-8000-CE7 Series User Manual, version 1.0.2 Page: 83 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 84: Add The Event Handling For The Control

    Step 2: Inserting the following code byte[] data = new byte[30]; PACNET.Sys.GetSDKVersion(data); MessageBox.Show(PACNET.MISC.WideString(data)); Tips & Warnings The “PACNET” of “using PACNET” is case- sensitive. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 84 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 85: Upload The Application To Wp-8000-Ce7

    FTP server. …… …… …… …... Step 1: On the Build menu, and then click Build [Project Name] WP-8000-CE7 Series User Manual, version 1.0.2 Page: 85 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 86 WP-8000-CE7, the corresponding PACNET.dll must be in the same directory as the .exe file. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 86 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 87: Execute The Application On Wp-8000-Ce7

    4.3.6. Execute the application on WP-8000-CE7 After uploading the application to WP-8000-CE7, you can just double-click it on WP-8000-CE7 to execute it. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 87 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 88: First Wp-8000-Ce7 Program In Visual C

    In this tutorial, we will assume that you have installed WP-8000-CE7 SDK on PC and used the Visual Studio 2008 for application development. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 88 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 89: Create A New Project

    Step 1: Start Visual Studio 2008 Step 2: On the File menu, point to New, and then click Project WP-8000-CE7 Series User Manual, version 1.0.2 Page: 89 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 90 Step 4: In the list of Templates, select MFC Smart Device Application Step 5: Specify a name and a location for the application and then click OK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 90 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 91 Step 7: On the next page of the wizard, select AM335x_WINCE7_SDK to be added to the project, and then click Next WP-8000-CE7 Series User Manual, version 1.0.2 Page: 91 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 92 Step 8: On the next page of the wizard, select Dialog based, and then click next Step 9: On the next page of the wizard, click next WP-8000-CE7 Series User Manual, version 1.0.2 Page: 92 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 93 Step 10: On the next page of the wizard, click next Step 11: On the next page of the wizard, click Finish WP-8000-CE7 Series User Manual, version 1.0.2 Page: 93 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 94: Configure The Platform

    On the Debug configuration toolbar, select Release and select AM335x_WINCE7_SDK(ARMv4I) as shown in the following illustration. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 94 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 95: Specify The Libraries Of The Pac Sdk

    It’s compatible with C++. In order to use a component in your application, you must first add a reference to it. Step 1: On the View menu, and then click Property Pages WP-8000-CE7 Series User Manual, version 1.0.2 Page: 95 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 96 Step 2: In left pane, click Linker, and then click Input Step 3: In the right pane, Type PACSDK.lib in the Additional Dependencies item WP-8000-CE7 Series User Manual, version 1.0.2 Page: 96 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 97: Add The Control To The Form

    Step 1: On the View menu, and then click Resource View WP-8000-CE7 Series User Manual, version 1.0.2 Page: 97 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 98 Dialog item to click the plug-in dialog Step 3: On the Toolbox panel, drag a Button control onto the form WP-8000-CE7 Series User Manual, version 1.0.2 Page: 98 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 99 Step 4: On the Properties panel, type Check the SDK version in the Caption field WP-8000-CE7 Series User Manual, version 1.0.2 Page: 99 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 100: Add The Event Handling For The Control

    Step 1: Double-click the button on the form Step 2: Inserting the following code char sdk_version[32]; TCHAR buf[32]; pac_GetSDKVersion(sdk_version); pac_AnsiToWideString(sdk_version, buf); MessageBox(buf,0,MB_OK); WP-8000-CE7 Series User Manual, version 1.0.2 Page: 100 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 101 Step 2: Inserting the following code into the header area #include “PACSDK.h” WP-8000-CE7 Series User Manual, version 1.0.2 Page: 101 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 102: Upload The Application To Wp-8000-Ce7

    FTP server. …… …… …… …... Step 1: On the Build menu, and then click Build [Project Name] WP-8000-CE7 Series User Manual, version 1.0.2 Page: 102 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 103 Step 2: Open the browser and type the IP address of WP-8000-CE7 Step 3: Upload the application to WP-8000-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 103 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 104: Execute The Application On Wp-8000-Ce7

    4.4.7. Execute the application on WP-8000-CE7 After uploading the application to WP-8000-CE7, you can just double-click it on WP-8000-CE7 to execute it. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 104 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 105: I/O Expansion Modules And Sdks Selection

    FRnet series I/O modules ET-7K ET-87P I-8120  CAN Bus  Local I/O CAN Bus series I/O modules I-8K/I-87K series I/O modules WP-8000-CE7 Series User Manual, version 1.0.2 Page: 105 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 106 .NET CF SDK RU-87Pn+I-87K series PACSDK.dll PACNET.dll  Other Specified I/O Module Native SDK .NET CF SDK Others PACSDK.dll PACNET.dll WP-8000-CE7 Series User Manual, version 1.0.2 Page: 106 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 107 I-87K series with PWM PACSDK_PWM.dll PACNET.dll For full details regarding I-87K series I/O modules and its demos, please refer to: http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/pac/applicabled_demo_for_87k_module. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 107 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 108 These features can improve the network reliability and transmission efficiency. Module Native SDK .NET CF SDK I-8120W i8120.lib i8120net_pac.dll WP-8000-CE7 Series User Manual, version 1.0.2 Page: 108 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 109: Api Resources And Demo References

    For full usage information regarding the description, prototype and the arguments of the functions, please refer to the “PAC Standard API Manual” WP-8000-CE7 Series User Manual, version 1.0.2 Page: 109 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 110: Pac Standard Apis For System Operation

     Backplane Access  UART  Backlight  Registry  Interrupt  Buzzer  Memory Access  LED System Operation WP-8000-CE7 Series User Manual, version 1.0.2 Page: 110 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 111: Vb.net Demos For Pac Standard Apis

    Shows how to read the name of a local I/O UART UART modules via a UART Displays information about how to operate the WatchDog WatchDog watchdog WP-8000-CE7 Series User Manual, version 1.0.2 Page: 111 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 112: C# Demos For Pac Standard Apis

    Shows how to read the name of a local I/O UART UART modules via a UART Displays information about how to operate the WatchDog WatchDog watchdog WP-8000-CE7 Series User Manual, version 1.0.2 Page: 112 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 113: Visual C++ Demos For Pac Standard Apis

    Shows how to read the name of a local I/O UART UART modules via a UART Displays information about how to operate the WatchDog WatchDog watchdog WP-8000-CE7 Series User Manual, version 1.0.2 Page: 113 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 114: Pac Standard Apis For Pac Expansion I/O

    The diagram below shows the types of the PAC IO APIs provided in the PACSDK. PAC IO Remote I/O Local I/O WP-8000-CE7 Series User Manual, version 1.0.2 Page: 114 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 115: Vb.net Demos For Pac Expansion I/O

    7k87k_basic This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 115 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 116 7k87k_dio This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 116 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 117: C# Demos For Pac Expansion I/O

    7k87k_basic This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 117 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 118 7k87k_dio This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 118 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 119: Visual C++ Demos For Pac Expansion I/O

    7k87k_basic This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 119 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 120 7k87k_dio This demo program is used by 7K or 87K series AI modules which connected through a COM port. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 120 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 121: Wp-8000-Ce7 Updates

    OS_Image The files of OS updates update_from_Micro_SD update_from_file The files of SDK updates Modbus nModbus PACNET PACSDK PlatformSDK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 121 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 122: Os Updates

    (We recommend that you use this one for more quicker and easier to update) 2. OS updates from microSD (Please refer to section 7.1.2) WP-8000-CE7 Series User Manual, version 1.0.2 Page: 122 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 123: Os Updates From Eshell

    ICP DAS web site. CD:\WinPAC_AM335x\WP-8x2x\PC_Tools\Eshell http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/pc_tools/eshell Step 3: Place the rotary switch in position 3, OS update mode WP-8000-CE7 Series User Manual, version 1.0.2 Page: 123 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 124 Select the device name which you want to update the OS image from the list. Step 6: Select the latest version of the OS image file WP-8000-CE7 Series User Manual, version 1.0.2 Page: 124 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 125 Step 9: Check the OS version Run the PAC Utility, and then select the Device Information tab to check the current OS version. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 125 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 126: Os Updates From Microsd

    The latest version of the installation package file can be found from ICP DAS web site. http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/os_image/update_from_esh ell_or_micro_sd\ Step 2: Plug the microSD card into SD slot WP-8000-CE7 Series User Manual, version 1.0.2 Page: 126 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 127 Step 5: Wait a few minutes for the following desktop to be displayed Step 6: Turn the rotary switch in position 0, normal mode WP-8000-CE7 Series User Manual, version 1.0.2 Page: 127 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 128 Step 8: Check the OS version Run the PAC Utility, and then select the Device Information tab to check the current OS version. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 128 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 129: Sdk Updates

    The SDK update files can be found separately on the CD that was provided with the package or by downloading the latest version from ICP DAS web site. CD:\WinPAC_AM335x\wp-8x2x\SDK\ http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-8x2x/sdk/ Modbus nModbus PACNET PACSDK PlatformSDK WP-8000-CE7 Series User Manual, version 1.0.2 Page: 129 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 130: Sdk Updates For Vb.net Or C

    The PACNET.dll file on PC can be placed anywhere only the solution can reference it. The PACNET.dll file on WP-8000-CE7 is located at the same directory as the .exe file. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 130 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 131: Sdk Updates For Vb.net Or Visual C

    C:\Program Files\Windows CE Tools\SDKs\AM335x_WINCE7_SDK\Lib\ARMv4I Step 3: Copy the latest version of DLL files to WinPAC The DLL files are located at: \System_Disk\ICPDAS\System WP-8000-CE7 Series User Manual, version 1.0.2 Page: 131 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 132: Download Center

    WP-8000-CE7 has a download center where you can access the latest version of the software, tools, demo programs, and related information. The WP-8000-CE7 Download Center can be found at: http://www.icpdas.com/root/support/download/pac/wp-8000-ce7/wp-8000-ce7_download_os_i mages.html WP-8000-CE7 Series User Manual, version 1.0.2 Page: 132 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 133: Tips - How To

    Tips – How to This chapter provides tips and a guided tour on using and maintaining the WP-8000-CE7. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 133 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 134: How To Online Debug The Wp-8000-Ce7 Program

     CMAccept.exe  ConmanClient2.exe  eDbgTL.dll  TcpConnectionA.dll Step 2: Run the ConmanClient2.exe and then CMAccept.exe on the WP-8000-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 134 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 135 Step 4: In the left pane, expand Device Tools node and select Devices Step 5: In the Show devices for platform:, select AM335x_WINCE7_SDK and then click Properties WP-8000-CE7 Series User Manual, version 1.0.2 Page: 135 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 136 Step 6: Click the Configure… Step 7: Select the Use specific IP address:, and then type the IP address of WP-8000-CE7 WP-8000-CE7 Series User Manual, version 1.0.2 Page: 136 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 137 Step 8: Click the OK, and then click OK to end the dialog WP-8000-CE7 Series User Manual, version 1.0.2 Page: 137 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 138 If the connection fails, as shown below, please repeat the step 2 to step 9 to try it again. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 138 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 139: How To Automatically Synchronize Wp-8000-Ce7 Clock With An Internet Time Server

    WP-8000-CE7 with an Internet time server. Step 1: Run the PAC Utility Step 2: On the General tab, press Configure button WP-8000-CE7 Series User Manual, version 1.0.2 Page: 139 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 140 Step 6: The WP-8000-CE7 will automatically synchronize with an internet time server regularly Step 7: Click the Update Now button to synchronize WP-8000-CE7 clock immediately WP-8000-CE7 Series User Manual, version 1.0.2 Page: 140 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 141: How To Control The User Account Control In Wp-8000-Ce7

    C. How to Control the User Account Control in WP-8000-CE7 User Account Control is a security feature that helps prevent unauthorized system changes to the WP-8000-CE7. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 141 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 142: How To Create A User Account

    Step 2: On the Login tab of the Network tab, click Login tab, type the User Name and Password, and then click Add button WP-8000-CE7 Series User Manual, version 1.0.2 Page: 142 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 143 Step 3: The user has been added to the allowed under the remote login and included in the following list Step 4: On the File menu, click Save and Reboot for changes to take effect WP-8000-CE7 Series User Manual, version 1.0.2 Page: 143 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 144: How To Telnet To Remote Login The Winpac From Pc

    Step 1: On the PC, open a MS-DOS command prompt 2. Type “cmd” Step 2: At the command prompt, type “telnet (IP address)” WP-8000-CE7 Series User Manual, version 1.0.2 Page: 144 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 145 Step 3: The connection has been set up, and then type the name and password Step 4: The remote login has been completed WP-8000-CE7 Series User Manual, version 1.0.2 Page: 145 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 146: How To Remove A User Account From The Login List

    Delete to delete the user from the login list Step 2: On the File menu, click Save and Reboot for changes to take effect WP-8000-CE7 Series User Manual, version 1.0.2 Page: 146 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 147: How To Change The Battery

    When the power of the battery is low, it’s recommended that the battery is replaced immediately, otherwise the RTC time will be reset. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 147 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 148 Tips & Warnings Please ignore the battery on the backplane. It uses to backward compatible the WP8x4x and WP8x3x device. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 148 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 149: How To Using The Practical Functions Of The 3G/4G I/O Module

    The description of the demo can be found by downloading the latest version from ICP DAS web site. http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-5231/document/faq/development/ W5-13_How_to_use_Auto_dial_GPRS_network_and_redial_when_the_network_disconnected_en WP-8000-CE7 Series User Manual, version 1.0.2 Page: 149 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 150: How To Use The Sms Function And Get The Gps Data

    The description of the demo can be found by downloading the latest version from ICP DAS web site. http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-5231/document/faq/development/ W5-14_How_to_use_the_SMS_function_and_get_the_GPS_data_en WP-8000-CE7 Series User Manual, version 1.0.2 Page: 150 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 151: How To Synchronize The System Time By Gps Data

    The description of the demo can be found by downloading the latest version from ICP DAS web site. http://ftp.icpdas.com/pub/cd/winpac_am335x/wp-5231/document/faq/development/ W5-15_How_to_Synchronize_the_system_time_by_GPS_data_en WP-8000-CE7 Series User Manual, version 1.0.2 Page: 151 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 152: Application Of Rs-485 Network

    The basic component of the RS-485 network consist of a Master Controller (or using a PC as a host controller), and some RS-485 devices. (I-7520 Series) RS-232/ RS-485 Converter WP-8000-CE7 Series User Manual, version 1.0.2 Page: 152 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 153: Daisy Chain Rs-485 Network

    (7510 series) to extend the network length. (I-7510 Series) (I-7510 Series) RS-485 Repeater RS-485 Repeater (I-7520 Series) RS-232/ RS-485 Converter WP-8000-CE7 Series User Manual, version 1.0.2 Page: 153 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 154: Star Type Rs-485 Network

    (I-7520 Series) RS-232/ RS-485 Converter (I-7510 Series) (I-7510 Series) (I-7510 Series) RS-485 Repeater RS-485 Repeater RS-485 Repeater WP-8000-CE7 Series User Manual, version 1.0.2 Page: 154 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 155 There is a better choice to use 7513 as a RS-485 hub on star type network. (I-7520 Series) (I-7513 Series) RS-232/ RS-485 RS-485 Hub Converter WP-8000-CE7 Series User Manual, version 1.0.2 Page: 155 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 156: Random Rs-485 Network

    (I-7510 Series) (I-7520 Series) RS-485 Repeater RS-232/ RS-485 Converter (I-7510 Series) RS-485 Repeater WP-8000-CE7 Series User Manual, version 1.0.2 Page: 156 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 157: Master/Slaves Settings

    COM3, located on the right side and its pull-high/pull-low resistor located on the bottom of the right side, as shown below. COM2 Power Board COM3 Master Slave WP-8000-CE7 Series User Manual, version 1.0.2 Page: 157 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 158 If the network is up to 1.2 KM, it will need a repeater (7510 series) to extend the network length. (I-7510 Series) (I-7510 Series) Master RS-485 Repeater RS-485 Repeater Slave Slave Slave Slave WP-8000-CE7 Series User Manual, version 1.0.2 Page: 158 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 159 When WinPAC as a master using COM3 communication interface, the pull-high/pull-low resistor located on the power board must adjust to enable as shown below. COM3 Master Slave WP-8000-CE7 Series User Manual, version 1.0.2 Page: 159 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 160 (I-7510) (I-7510 Series) (I-7510 Series) RS-485 Repeater RS-485 Repeater (I-7520 Series) RS-232/ RS-485 Converter Slave Slave Slave Slave WP-8000-CE7 Series User Manual, version 1.0.2 Page: 160 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...
  • Page 161 When WinPAC as a slave using COM3 communication interface, the pull-high /pull-low resistor located on the power board must set to “Slave” as shown below. COM3 Master Slave WP-8000-CE7 Series User Manual, version 1.0.2 Page: 161 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

  • Page 162: Revision History

    2. Added the information about the 3G/4G applications in Appendix E. 1.0.2 September 2020 Added the appendix about RS-485 network in Appendix F. WP-8000-CE7 Series User Manual, version 1.0.2 Page: 162 Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved.  E-mail: service@icpdas.com...

This manual is also suitable for:

Wp-8121-ce7Wp-8421-ce7Wp-8821-ce7

Table of Contents
