ICP DAS USA WP-5231PM-4GE-CE7 Quick Start

Download this manual

Packing List

In addition to this guide, the package includes the following items:

WP-5231PM-4GE-CE7

GSM/GPRS External Antenna

and GPS Active External Antenna

Technical Support

service@icpdas.com

www.icpdas.com

 For Desktop Web

WP-5231PM-4GE-CE7 Quick Start

microSD card and

micro SD/SD adapter

Resources

How to search for drivers, manuals and

spec information on ICP DAS website.

 For Mobile Web

Model Name

v1.2, October 2023

Wire Terminal * 16

M3x6L Screw * 4

44 mm DIN-Rail Clip

Screw Driver

Need help?

Do you have a question about the WP-5231PM-4GE-CE7 and is the answer not in the manual?

Page 1 WP-5231PM-4GE-CE7 Quick Start v1.2, October 2023 Packing List In addition to this guide, the package includes the following items: microSD card and M3x6L Screw * 4 WP-5231PM-4GE-CE7 micro SD/SD adapter 44 mm DIN-Rail Clip GSM/GPRS External Antenna and GPS Active External Antenna...
Page 2 Configuring the Boot Mode Before starting any installation, be sure that the switch is placed in the『0』position. Installing the SIM card and antenna 1) Push the ejection button to pull out the tray. 2) Put the SIM card in the tray, and then push the tray back into the socket 3) Screw the GSM/GPRS and GPS antenna tightly into the antenna connectors...
Page 3 Mounting the WP-5231PM-4GE-CE7 The WP-5231PM-4GE-CE7 can be mounted either directly to a wall/panel. Install the four mounting screws into the 4 keyhole mounting holes Fasten the screws securely Changing the User Interface Language Click Start menu, point to Settings, click Control Panel, and then click...
Page 4 Double-click the PAC Utility on the desktop, and then reboot the WP-5231PM-4GE-CE7 for changes to take effect Using PAC Utility to Manage the WP-5231PM-4GE-CE7 Run the PAC Utility to configure IP address (DHCP), FTP Server, Auto Execution files…, etc Reboot the WP-5231PM-4GE-CE7...
