Chapter 2 : INSTALLATION

• Table Top Mounting: The HD SCAN
• Rack Mounting:
IMPORTANT:
PAGE 6
™
can be used directly on a table: the unit is equipped with 4 plastic feet.
™
The HD SCAN is compatible with a 19" enclosure. Please follow the instructions below to install
™
the HD SCAN into a 19" rack:
Screw the supplied 19" brackets to the sides of the HD SCAN
Attach the HD SCAN
included).
• The openings in the front panel and in the rear panel are for cooling. Do not cover these
openings.
• Be sure that no weight is added to the HD SCAN
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and local
electrical codes.
™
to your rack by using 4 screws in the front panels (screws are not
™
.
™
in excess of 2 kg (4.4 lbs.).
HD SCAN™
