HD SCAN™

Chapter 6 : LCD FUNCTIONS DESCRIPTION

1 [INPUT MENU] + ENTER.
[input status] + ENTER.
1-1
Displays the input status.
• [INPUT]:
• [GENLOCK]: [none] = genlock signal not detected.
[Genlock H. ph.] + ENTER.
1-2
This function allows to adjust the genlock horizontal phase. Adjust with
[SOG input] + ENTER.
1-3
Select [yes] if your input signal is in RGsB (SOG), and valid with ENTER.
[H sync load] + ENTER.
1-4
Select the Horizontal sync load of your input signal with
2 [OUTPUT MENU] + ENTER.
[output status] + ENTER.
2-1
Displays the output status.
[output format] + ENTER.
2-2
Select one of the following format with
• 720p @ 59.94 Hz.
• 720p @ 60 Hz.
• 1035i @ 59.94 Hz.
• 1035i @ 60 Hz.
• 1080i @ 50 Hz.
• 1080i @ 59.94 Hz.
• 1080i @ 60 Hz.
[output rate] + ENTER.
2-3
Select one of the following functions with
• [internal] = The output format depends of the selected output format in LCD menu # 2-2.
• [genlock] = The output format is synchronized onto the genlock input format.
[sync type] + ENTER.
2-4
Select one of the following sync type with
• [tri-level] = tri-level sync.
• [bi-level] = bi-level sync.
[test pattern] + ENTER.
2-5
Select one item with
• [yes] = displays a test pattern onto the output.
• [no] = turns OFF the test pattern.
[XGA] = input format.
[60 Hz] = input frame frequency.
NOTE: To synchronized the XTD920-HDAG (analog genlock version), onto a 1035i or 1080i
format, you should select first the needed format (1035i or 1080i) with the LCD menu #
2-2, and then select [genlock] with the LCD menu # 2-3.
+ ENTER.
+ ENTER.
+ ENTER:
+ ENTER.
+ ENTER.
+ ENTER.
PAGE 11
