HD SCAN™

Chapter 1 : INTRODUCTION

1-1. SUPPLIED EQUIPMENT
™
• 1 HD SCAN
(XTD920).
• 1 Set of 19" Brackets.
• 1 AC power supply cord.
• 1 VGA cable (HD15 male / HD15 male).
• 1 CD-ROM (Remote Control Software).
• 1 User's manual.
1-2. GENERAL INFORMATION
™
The HD SCAN is a professional Computer to High-Definition TV Scan Converter, which allows to convert your
workstation, PC or MAC Graphic Images (Up to 1600x1280), into HDTV.
™
The HD SCAN features REAL TIME conversion with sized Aspect Ratio and Zoom up to 200%. The HDTV comes
with dual HDSDI output, and Tri Levels sync HD components.
• An HDSDI Genlock is also provided for further mixing with an external HDTV keyer.
• High performance Multi-levels of Anti-Flickers and smoothing Filters to significantly overcome the Sharpness &
Flickers of the HDTV output, thanks to its state of the art full RGB 16 million colors High Speed Hardware DSP.
™
1-3. HD SCAN REFERENCES
REFERENCES
XTD920-HDDG
XTD920-HDAG
HD SCAN
™
HD SCAN with HDSDI GENLOCK.
™
HD SCAN with HD analog GENLOCK.
™
DESIGNATIONS
PAGE 5
