Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued)
3 [IMAGE MENU] + ENTER.
[flicker filter] + ENTER.
3-1
Select one of the 8 levels of the anti flicker with
[Black Level] + ENTER.
3-2
Adjust the Black level with
[RGB Levels] + ENTER.
3-3
Select a color with
[under/over] + ENTER.
3-4
Select an item with
• [underscan] = the output image is full screen.
• [overscan] =
[H. smooth] + ENTER.
3-5
Select an item with
• [ON] = active the horizontal filter.
• [OFF] = inactive the horizontal filter.
[position status] + ENTER.
3-6
Displays the image position status.
[zoom status] + ENTER.
3-7
Displays the image zoom status.
[preset] + ENTER.
3-8
This function allows to set all the image parameters (flicker filter, Black level, RGB level, under/overscan, position
& size) to the factory settings.
4 [CONTROL MENU] + ENTER.
[panel locking] + ENTER.
4-1
This function allows to lock the front panel buttons. Select an item with
• [lock] = allows to lock the front panel push button.
• [unlock] = doesn't lock the front panel button.
NOTE: To unlock push simultaneously on ENTER and EXIT.
[version] + ENTER.
4-2
Status of the internal firmware: xxxx xxxx xxxx.
[freeze mode] + ENTER.
4-3
Select a mode corresponding to your application with
• [slow] = input source with static picture.
• [fast] = input source with motion picture.
NOTE: This function act on the front panel FREEZE button.
[erase memories] + ENTER.
4-4
This function allows to erase all the image settings memorized.
[default value] + ENTER.
4-5
This function allows to clear the following adjustments and set them to factory value:
FUNCTION
1-2 Genlock H Ph
1-3 SOG input
1-4 H sync load
2-2 Output format
2-3 Output rate
2-4 Sync type
2-5 test pattern
3-1 Flicker Filter
PAGE 12
+ ENTER.
+ ENTER and adjust the level with
+ ENTER.
the output is 10% bigger than in underscan mode.
+ ENTER.
POSITION
0
no.
Hi-Z.
1080i @ 59.94 Hz.
internal.
tri-levels.
no.
level 1.
and validate with ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
FUNCTION
3-2 Black level.
3-3 RGB levels.
3-4 under/overscan
3-5 H smooth
4-1 panel locking
4-2 freeze mode
Position & Size
Zoom
HD SCAN™
POSITION
0
0
underscan.
off.
unlock.
slow.
0
100 %.
