HD SCAN™

Chapter 9 : TECHNICAL SPECIFICATIONS

• COMPUTER INPUT
Line frequency:
Frame frequency:
Resolution:
Sync. types:
Levels:
Impedance:
• HD ANALOG GENLOCK (ACTIVE LOOPTHROUGH) - XTD920-HDAG version only.
Signal:
Impedance:
• HD SDI GENLOCK (ACTIVE LOOPTHROUGH) - XTD920-HDDG version only.
Signal:
Impedance:
• HD ANALOG OUTPUT (R-Y, Y, B-Y)
Levels:
Sync.:
Impedance:
• HD SDI OUTPUT
Data rate:
Impedance:
Up to 110 kHz.
Up to 130 Hz.
Up to 1600 x 1280.
RGBHV, RGB/S, RGsB (Sync On Green).
R, G, B = 3 x 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
R, G, B = 75 Ohms.
H = 75 Ohms or Hi-Z.
V = 75 Ohms.
HD analog BLACK (720p @ 59.94 or 60 Hz, 1080i @ 50, 59.94 or 60 Hz, 1035i @ 59.94 or 60 Hz).
75 Ohms.
HD SDI BLACK (720p @ 59.94 or 60 Hz, 1080i @ 50, 59.94 or 60 Hz, 1035i @ 59.94 or 60 Hz).
75 Ohms.
Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Tri-levels: ±0.3V (positive/negative).
Bi-levels: 0.3V (negative)
75 Ohms.
720p @ 59.94 or 60 Hz:
1080i @ 59.94 or 50 or 60 Hz: 1.5 Gbps serial digital output conforming to SMPTE 274M.
1035i @ 59.94 Hz:
1035i @ 60 Hz:
75 Ohms.
1.5 Gbps serial digital output conforming to SMPTE 296M.
1.5 Gbps serial digital output conforming to BTA-S004B.
1.5 Gbps serial digital output conforming to BTA- S001.
