Testing ISDN BRI functions
See ISDN Basic Rate Interface: Features (553-3001-380) for a detailed
description of how to configure relevant ISDN BRI packet data transmission
parameters in LD 17, LD 16, and LD 14.
Procedure 37
Perform a B-channel packet data transmission test using an external
packet handler
1 From an ISDN BRI B-channel packet data terminal, dial another local or
a remote ISDN BRI packet data terminal and establish an active call
connection.
After the call-originating ISDN BRI terminal receives an
acknowledgment that the receiving ISDN BRI terminal is ready, the
call-originating ISDN BRI terminal can begin transmitting packet data.
2 Verify that the transmitted data has been received successfully by
checking the transmitted information for accuracy. Read the information
on the screen or print it on the local printer.
3 Release the connection.
Repeat this test on other ISDN BRI packet data terminals as needed.
Procedure 38
Perform a D-channel packet data transmission test using an external
packet handler
1 From an ISDN BRI D-channel packet data terminal, dial another ISDN
BRI packet data terminal and establish an active call connection.
After the call-originating ISDN BRI terminal receives an
acknowledgment that the receiving ISDN BRI terminal is ready, the
call-originating ISDN BRI terminal can begin transmitting packet data.
2 Verify that the transmitted data has been received successfully by
checking the transmitted information for accuracy. Read the information
on the screen or print it on the local printer.
3 Release the connection.
