Proxy and Keypad Support

The ECU LAN is capable of working in multiple configurations with keypads, proxy readers, door strikes, and
magnetic door locks. While it supports dual proxy readers (one inside, one out) or one proxy reader and one
keypad, the ECU LAN cannot be used with two keypads.
ECU LAN Supports Proxy Reader and Keypad (1 each)
Or
Dual Proxy Readers (1 inside, 1 outside)
Specialized Door Control Modes
"Dual Proxy Mode" - When purchased for this hardware configuration, you will mount one Proxy Card Reader
inside your building and one outside. This is used for logging personnel in and out of facilities.
"Magnetic Door Mode" - This configurable mode may be used with doors equipped with magnetic door locks. In
this mode, the door will remain magnetically locked until unlocked via proxy card scan, Request-to-Exit button, or
motion sensor.
NOTE: Door violations occur when the door is opened without being unlocked. Pushing a Request-to-Exit button or
triggering the motion sensor after the intrusion will not cancel the violation.
"Lock When Closed Mode" - This mode causes the door to lock a few seconds after it has been detected closed,
and can be usefully combined with "Magnetic Door Mode" to ensure the door closes before being locked. In this
mode, if the door does not open after it has been unlocked, It will lock again after 2-3 seconds.
