XVME-560 Manual
September , 1984
Jumper/Switch
JlB
J2A
J2B
J3A
J3B
J4A
J4B
J5
J6
J7
J8
J9
Jl0A
Jl0B
J11
J13
J14A
J14B
J12
J15
J16
Switch 1
Switch 2
Table D-l. AIN Jumper/Switch List
Use
Enables IACKIN*/INACKOUT* daisy chain (always
installed).
Memory mapped operation.
Short I/O operation.
These jumpers select the kind of digital code that will
be produced as a result of reading an analog signal (see
Table 2-9).
These jumpers select one of the five input scaling
ranges used (see Table 2-8).
These jumpers select between single-ended or
differential input (see Table 2-7).
Test purposes only - J 12B
Used in grounding channel zero for a ground
reference (see Table 2-10).
Interrupt Level Select switches.
Address and Address Modifier module compare switches (see
Tables 2-2 and Z-3).
D-2
always installed.
