XVME-560 Manual
September, 1984
2.4.3 Supervisor/Non-Privileged
The AIN be configured to respond to only Supervisory access, or to both Non-
can
Privileged and Supervisory accesses, by selecting the position of Switch 7 (located in
Switch Bank 2, see Figure 2-2), as shown in Table 2-4 below.
Switch 7
Closed
.
Open
2.4.4 Address Modifier Reference
The following table (Table 2-5) indicates the actual VMEbus
respond to
AIN will
that the
sections.
previous two
Short
I/O
Standard
Address
Mode Selection
Table 2-4.
Privilege Mode Selected
Supervisory or Non-Privileged
Supervisory Only
based on the position of the two options discussed in the
Table 2-5. Address Modifier Code Options
Switches
7 8
Closed Closed
Closed
Open
Closed Open
Open Open
Privilege Options
Address Modifier Code
Jumper
AIN will respond to
J2
29H or 2DH
B
2DH only
B
A 39H or 3DH
A 3DH only
2-6
Address Modifier code
I
