XVME-560 Manual
September, 1984
2.1 INTRODUCTION
This chapter provides the information necessary to configure the AIN
in a VMEbus backplane cardcage.
discussed and the installation procedure is presented.
2.2 SYSTEM REQUIREMENTS
The AIN is a double-height VMEbus compatible module. To operate it must be
properly installed in a VMEbus backplane cardcage. The minimum system require-
ments for operation of the AIN are one of the following:
A host processor properly installed on the same backplane.
A)
A properly installed controller subsystem with the following features:
l
-- Data Transfer Bus Arbiter
-- System Clock driver
-- System Reset driver
-- time-out module
Bus
An example of such a controller subsystem is the XYCOM XVME-010
System Resource Module (SRM).
A host processor which incorporates an on-board controller subsystem.
B)
l
2.3 JUMPERS/SWITCHES
Prior to installing the AIN, it will be necessary to configure several jumper/switch
selectable options. These options fall into two categories: VMEbus-related
and Analog-to-Digital
VMEbus Options
Module base address, selected by switches 1-6 on Switch Bank 2.
l
Address space used by the module, selected by J2 and switch 7 on Switch
l
Bank 2.
Privilege level required to access module, selected by switch 8 on Switch
l
Bank 2.
The
l
interrupt
Bank 1.
Chapter 2
INSTALLATION
OR - -
--
conversion options.
level used
by
The components relevant to installation are
the module, selected by switches l-3 on Switch
2-1
for installation
options
