XVME-560 Manual
September, 1984
Table 2-12. Signal Location On JKl and JK2 for Differential Input
JKl
Pin Signal
1 Chan. 0 Lo
2 Chan. 0 Hi
3 Analog gnd
4 Chan. 1 Hi
5
Chan. 1 Lo
6 Analog gnd
7 Chan. 2 Lo
8 Chan. 2 Hi
9 Analog gnd
Chan. 3 Hi
1 0
Chan. 3 Lo
1 1
1 2 Analog gnd
13 Chan. 4 Lo
14 Ghan. 4 Hi
15 Analog gnd
16 Chan. 5 Hi
17 Chan. 5 Lo
18 Analog gnd
19 Chan. 6 Lo
2 0 Chan. 6
Hi
2 1 Analog gnd
2 2 Chan. 7
Hi
2 3 Chan. 7 Lo
24 Analog gnd
2 5 Chan. 8
L
O
2.6 MODULE INSTALLATION
The XYCOM VMEbus modules can accommodate typical VMEbus backplane construc-
tion. Figure 2-6 shows a standard VME chassis and a typical backplane configuration.
There are two rows of backplane connectors depicted (i.e., the Pl backplane and the
P2 backplane). The AIN requires only the Pl connector.
Pin Signal
2 6 Chan. 8 Hi
2 7 Analog gnd
2 8 Chan. 9 Hi
2 9 Chan. 9 Lo
3 0 Analog gnd
31 Chan. 10 Lo
3 2 Chan. 10 Hi
3 3 Analog gnd
3 4 Chan. 11 Hi
3 5 Chan. 11 Lo
3 6 Analog gnd
3 7 Chan. 12 Lo
3 8 Chan. 12 Hi
39 Analog gnd
40 Chan. 13 Hi
4 1 Chan. 13 Lo
4 2 Analog gnd
43 Chan 14 Lo
44 Chan. 14 Hi
45. Analog gnd
4 6 Chan. 15 Hi
4 7 Chan. 15 Lo
48 Analog gnd
49 No connection
50 No connection
.
JK2
Pin Signal
1 Chan. 16 Lo
2 Chan. 16 Hi
3 Analog gnd
4 Chan. 17 Hi
5 Chan. 17 Lo
6 Analog gnd
7 Chan. 18 Lo
8 Chan. 18 Hi
9 Analog gnd
10 Chan. 19 Hi
Chan. 19 Lo
1 1
12
Analog gnd
1 3 Chan. 20 Lo
14 Chan. 20 Hi
15 Analog gnd
16 Chan. 21 Hi
1 7 Chan. 21 Lo
18 Analog gnd
19 Chan. 22 L o
20 Chan. 22 Hi
2 1 Analog gnd
2 2 Chan. 23 Hi
2 3 Chan. 23 Lo
24 Analog gnd
2 5 Chan. 24 Lo
2-14
Pin Signal
26 Chan. 24 Hi
27 Analog gnd
28 Chan. 25 Hi
29 Chan. 25 Lo
30 Analog gnd
Chan. 26 Lo
3 1
3 2 Chan. 26 Hi
33 Analog gnd
3 4 Chan. 27 Hi
3 5 Chan. 27 Lo
3 6
Analog gnd
3 7 Chan. 28 Lo
3 8 Chan. 28 Hi
3 9 Analog gnd
4 0 Chan. 29 Hi
Chan. 29 Lo
41
4 2 Analog gnd
4 3 Chan. 30 Lo
4 4 Chan. 30 Hi
4 5 Analog gnd
4 6 Chan. 31 Hi
4 7 Chan. 31 Lo
4 8 Analog gnd
49 Digital gnd
50 Ext Trigger
