Weco Power Pulse 400 Software Update Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Power Pulse 322T-402T-502T
Power Pulse 322AC/DC-402AC/DC-502AC/DC
Pioneer Pulse 321MSR, Pioneer 321 Pulse
GB
Power Pulse 400-500
Power Pulse 402-502
WF-104, WF-108
RC-104, RC-204, IR-01
Micro Pulse 302MFK
Software update manual
WECO srl
Via S. Antonio, 22 - BELVEDERE
36056 TEZZE SUL BRENTA (VICENZA) ITALY
Tel.+39 0424 561943 – Fax +39 0424 561944
www.weco.it - E-mail info@weco.it
Cod.006.0001.1700
02/09/2016 v1.1
ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Weco Power Pulse 400

Summary of Contents for Weco Power Pulse 400

  • Page 1 ENGLISH WECO srl Via S. Antonio, 22 - BELVEDERE 36056 TEZZE SUL BRENTA (VICENZA) ITALY Tel.+39 0424 561943 – Fax +39 0424 561944 www.weco.it - E-mail info@weco.it Power Pulse 400-500 Power Pulse 402-502 Power Pulse 322T-402T-502T Power Pulse 322AC/DC-402AC/DC-502AC/DC WF-104, WF-108...

  • Page 2: Table Of Contents

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH CONTENTS INSTALLATION OF THE SOFTWARE ON THE PC ..................3 SOFTWARE UPDATE KIT CONTENTS ....................... 3 PREPARATION ............................3 SETTING THE PC COMMUNICATION PORT ....................4 1.3.1 PROCEDURE WITH WINDOWS XP OPERATING SYSTEM ..................4 1.3.2 PROCEDURE WITH WINDOWS 7 OPERATING SYSTEM .....................

  • Page 3: Installation Of The Software On The Pc

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH INSTALLATION OF THE SOFTWARE ON THE PC SOFTWARE UPDATE KIT CONTENTS Code 010.0000.0037 Complete software update kit Code 022.00002.0178 RS232-RS232 communication cable Code 022.0002.0152 RS232-microfit 8 pin communication cable Code 022.0002.0153 RS232-minifit 8 pin communication cable Code 006.0002.0041 USB/RS232 adapter Codice 010.0000.0065...

  • Page 4: Setting The Pc Communication Port

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH SETTING THE PC COMMUNICATION PORT 1. Connect the USB-RS232 adapter to the PC. 2. Identify the number of the communication port in which the adapter is inserted as described below: 1.3.1 PROCEDURE WITH WINDOWS XP OPERATING SYSTEM Right-click on MY COMPUTER.
  • Page 5 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH The DEVICE MANAGER window will appear. Left-click the PORTS (COM and LPT) button. Check the number of the USB SERIAL PORT. Make a note of the number. Close the window by pressing this button: 5/18...

  • Page 6: Procedure With Windows 7 Operating System

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 1.3.2 PROCEDURE WITH WINDOWS 7 OPERATING SYSTEM Left-click on CONTROL PANEL. The CONTROL PANEL window will appear. Select SMALL ICONS in the VIEW tab. Left-click on DEVICE MANAGER. 6/18...
  • Page 7 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH The DEVICE MANAGER window will appear. Left-click the PORTS (COM and LPT) button. Check the number of the USB SERIAL PORT. Make a note of the number. Close the window by pressing this button: 7/18...

  • Page 8: Programming Setting

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH PROGRAMMING SETTING 3. Start the previously installed FLASHPRG program by double left- clicking on the following icon: The FLASHPRG program window will appear. 3. Enter the number of the USB SERIAL CONTROLLER port displayed previously in the DEVICE MANAGER window in the VIA COM-PORT 4.

  • Page 9: Programming The Unit

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH PROGRAMMING THE UNIT WARNING! Before starting the programming procedure disconnect the welding cables from all the unit's welding sockets. Failure to comply with this instruction can result in serious damage to the programming controller. 1. Set the welding power source ON/OFF switch to “O” to switch the unit off. 2.

  • Page 10: 321 Power Pulse: Rs232 Connector

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 2.1.3 321 POWER PULSE: RS232 CONNECTOR COM1: Programming connector for the process circuit board. (For programming with the following software: 321_PULSE_COM1_…_.mhx) COM2: Programming connector for the motor circuit board. (For programming with the following software: 321_PULSE_COM2_…_.mhx) 10/18...

  • Page 11: Programming Via Connector Directly On The Circuit Boards

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH PROGRAMMING VIA CONNECTOR DIRECTLY ON THE CIRCUIT BOARDS DANGER! Maintenance procedures must be carried out by qualified technical personnel. Disconnect the unit from the mains power supply before opening it and before performing any maintenance procedures. Wait at least 5 minutes after switching off the unit before opening it to gain access to internal electrical parts.

  • Page 12: Wf-104: Circuit Board 050.0001.0078

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 2.2.2 WF-104: CIRCUIT BOARD 050.0001.0078 1. Disconnect the unit from the mains power supply. 2. Connect communications cable P/N 022.0002.0152 to connector CN2 on circuit board P/N 050.000x.0078. INFORMATION With circuit board P/N 050.0001.0078 insert cable P/N 022.0002.0152 using caution to ensure the tab of the connector is facing the flat cable and that all the pins are inserted.

  • Page 13: Rc-104: Circuit Board 050.0001.0078

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 2.2.3 RC-104: CIRCUIT BOARD 050.0001.0078 1. Disconnect the unit from the mains power supply. 2. Connect communications cable P/N 022.0002.0152 to connector CN2 on circuit board P/N 050.000x.0078. INFORMATION With circuit board P/N 050.0001.0078 insert cable P/N 022.0002.0152 using caution to ensure the tab of the connector is facing the flat cable and that all the pins are inserted.
  • Page 14 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH … (continue from page 9) 3. Press the BROWSE button. 4. The OPEN window appears. 5. Find the .mhx extension file to be loaded. The update files are on the software update CD. The files can be sent on request by e-mail in .rar or .zip compression format.
  • Page 15 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 7. Set the welding power source ON/OFF switch to “I” to switch on the unit. The programming stage now starts… 8. When programming is completed press the QUIT button. 9. Close the window by pressing this button: 10.

  • Page 16: Errors During The Programming Procedure

    Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH ERRORS DURING THE PROGRAMMING PROCEDURE Communication port not recognized. - Disconnect the USB/RS232 adapter from the PC port, wait 30 seconds and then reconnect it. - Make sure you have entered the correct number of the USB SERIAL PORT in the VIA COM-PORT field.
  • Page 17 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 17/18...
  • Page 18 Cod.006.0001.1700 02/09/2016 v1.1 ENGLISH 18/18...
