Install the Access Point Under-Seat

Related Topics
AP560i Purchase Order Information
Install the Access Point Under-Seat
About This Task
The AP560i is used with the EIO-03 or EIO-04 mounting kit during the under-seat installation
procedure.
The EIO-03 or EIO-04 under-seat mounting kit can be installed on a:
Procedure
1. Slope
2. Flat surface such as a stadium floor
3. Riser, with EIO-02 silicone rubber kit

Install the EIO-04 Under-Seat Enclosure and the Access Point on a Slope

Install the EIO-04 under seat enclosure with the AP560i access point on a stadium slope.
Before You Begin
Table 9: Hardware requirements for slope installation
Item quantity
1
6
4
2
2
2
1
1
1
1
Attach the metal sloping bracket on a slope:
1. Using the metal sloping bracket as a template, mark and drill two holes in the concrete.
2. Insert the anchors without the nuts and washers.
18 ExtremeWireless™ AP560i Access Point
on page 11
Note
The best practice is to install the EIO-03 under-seat mounting kit horizontally. The EIO-03
under-seat mounting kit can be installed vertically on a slope, a flat surface or stadium
riser.
Description
AP560i access point
10 mm M6 screws with integral washers
75 mm service panel shoulder screws
Anchor posts
Flat washers for anchors
Lock washers for anchors
Metal "L" bracket
Plastic service panel base
Plastic service panel top with captive screw
Metal sloping bracket
Install the Access Point
