AP560i Overview

AP560i Features

AP560i Purchase Order Information
The AP560i access point is a cloud-ready, stadium-optimized Wi-Fi 6, and 802.11ax/ac/ abgn outdoor
access point with internal antenna.
The AP560i access point caters to the stadium and outdoor environment by supporting high density of
users and devices. The AP560i access point offers flexible deployment options, and can be mounted
under a seat, to a pole, or to a wall.
Note
The AP560i requires a minimum base firmware of WiNG 7.1.1.
AP560i Features
Learn about the features of AP560i access point.
•
Radios: Three radios
◦ Two WiFi radios: 1 dual-band, 2.4 GHz and 5 GHz, and 1 band-locked 5GHz radio
◦
1 IoT Radio (2.4 GHz)
•
Two Ethernet ports:
◦
1 × 100/1000/2500/5000 Mbps auto-negotiation Ethernet port, RJ45
◦ 1 × 10/100/1000 Mpbs auto-negotiation Ethernet port, RJ45
•
Dimensions: 11.3 in. x 10 in. x 2.9 in. (288 mm x 254 mm x 75 mm)
•
LEDs: Two top-mounted LEDs – all LEDs will be on during reset
•
Security locks:
◦
One Kensington lock
◦ One security hanger
•
Power: PoE 802.3at
•
Antenna:
◦ Eight WiFi internal antennas
◦
One BLE internal antenna
•
Temperature:
◦
Operating temperature: -40°F to +131°F (-40°C to +55°C)
8 ExtremeWireless™ AP560i Access Point
