Install the EIO-04 Under-Seat Enclosure with the Access
Point on a Flat Surface
7. Run the cable through the conduit and add the RJ45 connectors to the wires.
For more information about GE1 or GE2 cable, refer to
8. Attach the metal L bracket to the access point:
a. Attach the metal "L" bracket to the gland side of the AP560i access point using two M6 screws.
b. Torque the screws to 35 in-lbs.
9. Install the access point on the slope:
a. Align and center the alignment holes of the access point and the side tab extension holes, and
attach the access point to the tabs using two M6 screws.
b. Attach the gland side of the access point, that has the "L" bracket to the metal sloping bracket
using two M6 screws.
c. Push the access point to the rear as far as it would go.
d. Torque the screws to 35 in-lbs.

Install the EIO-04 Under-Seat Enclosure with the Access Point on a Flat Surface

Learn how to install the EIO-04 under-seat enclosure with the AP560i access point on a flat surface.
Before You Begin
Table 10: Hardware requirements for flat surface installation
Item quantity
1
4
4
2
1
1
4
Procedure
1. Attach a metal "L" bracket on each side of the AP560i access point using two M6 screws for each
bracket.
2. Torque the M6 screws to 35 in-lbs.
3. Use the metal "L" brackets as a template, mark four hole centers, and drill in the concrete.
4. Insert four concrete anchors into the holes without the washers and nuts.
5. Place the metal "L" bracket over the threaded anchor posts and put on the flat-washer, the spring
washer, and the nut on each side.
20 ExtremeWireless™ AP560i Access Point
Note
The cable must have 1 in. bend radius and be accessible to the glands on AP560i access
point.
Description
AP560i access point
M6 screws with integral washers
75 mm service panel shoulder screws
Metal "L" bracket
Plastic service panel base
Plastic service panel top with one captive screw
Concrete anchors with nuts, washers, anchor posts, and anchor
sleeves
Install the Access Point
Connect the GE1 or GE2 cable topic.
