4. CONTROL INPUTS.

The next figure provides the electrical specification of all V2 control inputs. Each input is individually
described below.
4.1 C ONTROL TERMINALS
L
230Vac
N

4.2 TERMINAL DESCRIPTIONS

Control voltage terminals.
Input terminal for control board voltage supply (230V +/-10%). Other voltage rates are also available on
demand.
Between 1 and 2 there is an empty terminal with no se to secure electrical isolation.
Terminals 1-6 Output relays
Fault: It switches in case of any fault condition.
Instantaneous: It switches when starting/ stopping
NOTE: Maximum current per conta
POWER ELECTRONICS User's Manual V2
DIGITAL OUTPUTS
FAULT INSTANT
RELAY RELAY
1 2 3 4 5 6
Fig. 5: V2 Control Terminals.
u
.
1
FAULT
2
RELAY
3
4
INSTANT
5
RELAY
6
Fig. 6: Output relay.
ct 5A at 230V.
ELECTRONIC SOFT-STARTER
DIGITAL INPUTS
7 8 9 10 11 12 13
DT0038E
A1
A2
A1
A2
DT0048F
V2MT01II | 13
