2. ELECTRICAL SPECIFICATIONS.

INPUT
Input voltage:
Supply frequency:
Control Voltage:
OUTPUT
Output voltage:
Output frequency:
Efficiency (at full load):
ENVIRONMENTAL CONDITIONS
Ambient temperature:
Altitude losses:
Humidity:
Protection degree:
Cooling:
PROTECTIONS
V2 PROTECTIONS
SETTINGS
NOTE: V2 IP54 number of starts per hour is limited to 5
OUTPUT SIGNALS
LED'S INDICATIONS
POWER ELECTRONICS User's Manual V2
230-400V(~3 phases), ±10%
47-62 Hz
230V +/-10%, others under demand
0 -100% Supply Voltage
47-60 Hz
> 99%
Operating: 0 to +40ºC
Storage: -10ºC to +70ºC
>1000m 1% each 100m, maximum 3000m
95%@ 40ºC non-condensation
IP00
Natural
Input phase loss
Starting current limit
Rotor locked
Motor overload (thermal model)
Underload
Phase unbalance
General fault
V2 over temperature
Initial torque
Acceleration ramp
Deceleration ramp
Overload: 0.8 to 1.2 In
Overload curve
Underload: 0.2 to 0.6 In
Underload curve
Current limit: 1 to 5 In
2 changeover relays (5A 230Vac non inductive)
· Fault: It opens in case of any fault condition
· Instantaneous: Its position changes when starting and stopping
LED 1 Run
LED 2 Ready
LED 3 Overload warning / Underload fault
LED 4 Overload Fault
LED 5 Over temperature
LED 6 General fault
ELECTRONIC SOFT-STARTER
