General

HVZ-uni
V7
3
General

3.1 Authorized use

This clamp was developed to meet the need of builders for a device to mechanically install awide range
of pavers which are delivered to the site in ready-to-install formation. The hydraulic installation clamp
may be used in connection with any carrier, such as wheel-loaders, compact loaders, excavators, mobile
excavators, truck-mounted crane special machines (VM203/204).
To operate the hydraulic installation clamp 2 separate hydraulic circuits are required on the carrier.
With the device (HVZ-uni) it is possible to handle one layer of pavers. Do not exceed the carrying
capacity and the max. width of the device HVZ-uni.
Only pavers in good quality are allowed for laying. Pavers with „feet, bellies and blind spacers" are not
allowed", because the complete bricklayer could fall out of the device.
The device is equipped with:
Er's
The device is only designed for the use specified in this documentation.
Every other use is not authorized and is forbidden!
All relevant safety regulations, especially regulations of the declaration of conformity, and
Prohibition
additional local health and safety regulations have to be observed.
Adjustable main tension, movable on low-maintenance
steel-polyamid sliders.
Adjustable side gripping direction for accurate positioning
of the laying formation.
Two operating handles for optimal guiding of the clamp.
An height adjustable support for a variable gripping
depth.
An oil pressure gauge.
With pressure control valve to avoid overload.
With spring-mounted steel-lamellas for gripping.
18/06/12
6 / 36
