6.2 Settings of the HVZ uni

The HVZ-uni has the following basic settings:
V Height of the operator
handle
P Opening width
side clamp direction
B Position cylinder
retaining pin,
main clamp direction
facing bedding sand
I Positionadjustment
gripping depth facing
bedding sand
N Gripperlength
main clamp direction
(optional)
E Position centering chain
facing bedding sand
H Gripping depth facing
bedding sand
X1 Readjustment
guidance clearance
main clamp direction
M Gripperadjustment
main clamp direction
S Positioningadapter
V
P
B
I
N
E
H
X1
M
S
