Specification

■Specifications

Item
Rated charge amount range
Minimum display unit
Measuring distance
∗ 1
Power supply
Display accuracy
Enclosure
Operating temp. range
Operating humidity range
Material
Weight
Standard
Accessories
∗1: 2 A alkali dry cell batteries (2 pcs.) are not included, and must be prepared separately.
∗2: When using new batteries at ordinary temperature.

■Characteristics graph (for reference)

There will be difference between the actual value and displayed value of charged potential depending on
the measuring distance between the measured target and the sensor. The shaded part shows the
deviation in a measuring distance range of 25 to 75 mm.
0.1 kV (±1 kV to 20 kV), 0.01 kV (0 to ±0.99 kV)
50 mm (between the detection port and measured target)
1.5 VDC 2 A alkali dry cell battery (2 pcs.) (continuously used for 15 hours
o
Operation: 0 to 40 C, Storage: -10 to 60
Operation/Storage: 35 to 85%R.H. (no condensation)
Display: PC/ABS, Sensor: ABS
Ground wire (IZH-A-01), Soft case (IZH-B-01)
-17-
IZH10
±20.0 kV
±5%F.S. ±1 digit
IP40
o
C (no freezing and condensation)
85 g (excluding batteries)
CE marking
∗ 2
)
