SMC Networks PFMV3 Series Operation Manual

Flow monitor
Hide thumbs Also See for PFMV3 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
No.PF##-OMN0005
Flow Monitor
PRODUCT NAME
PFMV3## Series
MODEL / Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFMV3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks PFMV3 Series

Summary of Contents for SMC Networks PFMV3 Series

  • Page 1 No.PF##-OMN0005 Flow Monitor PRODUCT NAME PFMV3## Series MODEL / Series...

  • Page 2: Table Of Contents

    Table of Contents Safety Instructions Model Indication Method Names and Functions of Individual Parts Definition and terminology Mounting and Installation Installtion Wiring Flow setting Function setting Setting at the shipment from a factory F0 Setting of auto-preset F1 Operation of OUT1 F2 Operation of OUT2 F3 Setting of response time F4 Selection of External input...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of "Caution", "Warning" or "Danger". They are all important notes for safety and must be followed in addition to International standards (ISO/IEC), Japan Industrial Standards (JIS) and other safety regulations *1) ISO 4414: Pneumatic fluid power - - General rules relating to systems.
  • Page 4 Caution 1. The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5 Operator ♦This operation manual has been written for those who have knowledge of machinery and apparatus that use pneumatic equipment and have full knowledge of assembly, operation and maintenance of such equipment. ♦Please read this operation manual carefully and understand it before assembling, operating or providing maintenance to the product.
  • Page 6 ■NOTE ○Follow the instructions given below when designing, selecting and handling the product. ●The instructions on design and selection (installation, wiring, environment, adjustment, operation, maintenance, etc.) described below must also be followed. ∗Product specifications •The direct current power supply to combine should be UL approved as follows. Circuit (of class 2) which is of maximum 30Vrms (42.4 V peak), with UL 1310 class 2 power supply unit or UL 1585 class 2 transformer.
  • Page 7 ∗Wiring •Do not pull the lead wires. In particular, never lift a product equipped with fitting and piping by holding the lead wires. Otherwise damage to the internal parts can result, causing malfunction or to be off the connector. •Avoid repeatedly bending or stretching the lead wire, or placing heavy load on them. Repetitive bending stress or tensile stress can cause the sheath of the wire to peel off, or breakage of the wire.
  • Page 8 ∗Environment •Do not use the product in area that is exposed to corrosive gases, chemicals, sea water, water or steam. Otherwise failure or malfunction can result. •Do not use in a place where the product could be splashed by oil or chemicals. If the product is to be used in an environment containing oils or chemicals such as coolant or cleaning solvent, even for a short time, it may be adversely affected (damage, malfunction, or hardening of the lead wires) •Do not use in an area where surges are generated.
  • Page 9 ∗Adjustment and Operation •Turn the power on after connecting a load. Otherwise it can cause excess current causing instantaneous breakage of the product. •Do not short-circuit the load. Although error is displayed when the product load is short circuit, generated excess current lead to cause the damage of the product.

  • Page 10: Model Indication Method

    Model Indication Method No.PF##-OMN0005...
  • Page 11 Option 1 None Power and output lead wire with cable Option 2 None Bracket Panel mount adapter Panel mount adapter + Front protection cover -10- No.PF##-OMN0005...
  • Page 12 Option 3 None Connector for sensor Part number for options Model No. Option Remarks ZS-28-A Power and output lead wire with cable (2 m) ZS-28-B Bracket M3 x 5 L (2 pcs.) ZS-28-C Connector for sensor 1 pc. ZS-27-C Panel mount adapter M3 x 8 L (2 pcs.) ZS-27-D Panel mount adapter + Front protection cover...

  • Page 13: Names And Functions Of Individual Parts

    Names and Functions of Individual Parts Description Function Output (OUT1) Display (Green) Light is on when output OUT1 is on. Output (OUT2) Display (Red) Light is on when output OUT2 is on. Displays flow value, set mode condition, and error code. LCD Display Indication color is selectable from Red and Green depending on output (OUT1) condition.

  • Page 14: Definition And Terminology

    ■Definition and terminology Terminology Definition A type of variable output that has a value proportional to the Analog output measured quantity. When the analog output is in the range of 1 to 5 V or 4 to 20 mA, it will vary continuously, following the change of flow. This function calculates and sets a rough set value automatically Auto-preset based on the on-going operation.
  • Page 15 Terminology Definition Temperature range in which product can be stored without being Storage temp. range damaged while power supply and flow not applied. Humidity range in which product can be stored without being Storage humidity. range damaged while power supply and flow not applied. Output type that has only 2 conditions, ON or OFF.

  • Page 16: Mounting And Installation

    Mounting and Installation ■Installation How to mount •Mount the optional bracket and panel mount adapter to the product. Mounting with bracket Fix the bracket to the product with the set screws M3 x 5 L (2 pcs.) attached. The tightening torque must be 0.5 to 0.7Nm. Mounting with panel mount adapter Fix the panel mount adapter to the product with the set screws M3 x 8 L (2 pcs.) attached.
  • Page 17 Panel cut dimensions Panel thickness: 0.5 to 6 mm Separate Corner: R2 or less Two or more in row n: The number of products Vertical Horizontal Notice when removing the flow monitor The flow monitor with adapter for panel mounting can be removed from facility by making hook of the product wide as illustration after removing two screws.

  • Page 18: Wiring

    ■Wiring Connection •Make connection after turning the power off. •Install the lead wire separately from the route for power cable or high-voltage cable. Otherwise, malfunction may potentially result due to noise. •Be sure to ground Terminal FG when using a switching regulator obtained on the commercial market. If analog output is performed connecting to a switching regulator obtained on the market, switching noise will be superimposed and product specification can no longer be met.
  • Page 19 Connector Connecting/Disconnecting When connecting the connector, insert it straight onto the pin holding the lever and connector body between fingers and lock the connector by pushing the lever claw into the square groove in the housing until connector clicks. (When disconnecting the connector, push down the lever by thumb to disengage the lever claw from the square groove.
  • Page 20 Internal circuit and wiring example When the lead wire with SMC power and output lead wire (type ZS-28-A) is used, the colors of wire (Brown, Black, White, Gray, Blue) will apply as shown on circuit diagram. PFMV300 NPN open collector output: 2 outputs Max.
  • Page 21 PFMV303 PNP open collector output: 2 outputs Max. 80 mA Residual voltage 1 V or less Analog output: 1 to 5 V Output impedance: Approx. 1 kΩ PFMV304 PNP open collector output: 2 outputs Max. 80 mA Residual voltage 1 V or less Analog output: 4 to 20 mA Max.

  • Page 22: Flow Setting

    Flow Setting What is measurement mode? The measurement mode is the condition where the flow is detected and indicated, and the switch function is working. This is the basic mode where the setting change and other function settings are available as necessary.
  • Page 23 <How to perform> ∗: The flow monitor will also output during setting. 1. Press the button once in the measurement mode. [LLL] is displayed during measurement mode when the sensor is not connected. 2. [n_1] or [P_1] and set value are displayed by turn. 3.

  • Page 24: Function Setting

    Function setting Function selection mode It measurement mode, press the button for 2 seconds or longer to display [F 0]. Display [F((], and point the mode to change the setting of each function. Press the button for 2 seconds or longer at function selection mode to return to measurement mode. ■Setting at the shipment from a factory At the time of shipment, the settings are performed as follows.

  • Page 25: F0 Setting Of Auto-Preset

    ■[F 0] Set auto preset This function is capable of calculating the specified set value automatically based on the on-going operation. <Operation> Press the button at function selection mode to display [F 9] Press the button. Move on to set auto preset. Set aoto pre-set Return to measurement mode, and press the button for fine adjustment of set value.
  • Page 26 ●Switch set value during auto preset function mode. Auto preset is capable of calculating the specified set value automatically based on the on-going Operation. ・Auto-preset set value Hysteresis mode Window comparator mode ・P1L＝B ・P_1＝A－(A－B)/4 ・P1H＝A ・H_1＝(A－B)/2 ・H_1＝5 digit value 1 digit means set minimum unit (n_1=B+(A-B)/4 (In reverse output, P1L, P1H in reverse output node)

  • Page 27: F1 Operation Of Out1

    ■[F 1] Operation of OUT1 Set output method of OUT1. The output is provided in relation to the set value. Display color depends on OUT1 output condition. In the default setting, green lights when output is turned on. Red lights when output turned off. <Operation>...
  • Page 28 Voltage setting Set voltage based on setting procedure on page 21 Hysteresis mode: [n_1] Window comparator mode: [n1L] [n1H] ∗: At normal output, n becomes P. Press the button to set. Move on to hysteresis change. Hysteresis change [H_1] and set value are displayed by turn. Press the button to select hysteresis.
  • Page 29 ●List of output mode ∗: Operation becomes unstable if hysteresis mode or window comparator mode during unstable condition such as fluid fluctuating. This case, keep interval between set values and start using after confirming stable operation. -28- No.PF##-OMN0005...

  • Page 30: F2 Operation Of Out2

    ■[F 2] Operation of OUT2 Set output method of OUT2. Display color depends on OUT1 output, and is not set with this function. <Operation> Press the button at function selection mode to display [F 2]. Move on to output mode selection. Press the button.

  • Page 31: F4 Selection Of External Input

    ■[F 4] External input This function is available when external input function is equipped. (Input signal: Connect input wire to GND for 5 ms or longer) *: [･･･] is displayed when external input function is not available. Selection of flow indication changes the selected content of the external input function. Voltage indication (Refer to page 31) Auto-shift: Function to perform output to relative change referring the instantaneous flow when signal is input.
  • Page 32 Select connect sensor [Cos] and set value are displayed by turn. Press the button to select connect sensor. Press the button to set. Return to function selection mode. Setting of [F 4] External input completed -31- No.PF##-OMN0005...
  • Page 33 □Selection of external input during flow indication [inP] and set value are displayed by turn. Press the button to select connected sensor. The setting of selected output is initialized when switching the selection of the externalinput. [rA1]：Auto-shift input is valid for OUT1 only [rA2]：Auto-shift input is valid for OUT2 only [rAb]：Auto-shift input is valid for both OUT1 and OUT2 [r01]：Auto-shift zero input is valid for OUT1 only...
  • Page 34 Operation example of auto-shift (When voltage indication mode) <Ex.> This function is used during the confirmation of adsorption/release as a solution for voltage (=flow rate) change due to source pressure fluctuation or nozzle diameter change. When auto-shift function is not used, even if the work is adsorbed, switching operation is not made when the voltage (=flow rate) amount fluctuates.
  • Page 35 •When auto-shift in used Switch set value: n_1=-1.00, H_1=0.40 (Revers output, hysteresis mode) •ON point: (Flow when auto-shift is input)+(n_1) ON/OFF point of this setting ⋅⋅⋅ •OFF point: (Flow when auto-shift is input)+(n_1)+(H_1) Setting range when auto-shift function is selected is -4.40 to 4.40. If relative set value after the auto-shift is out of upper or lower limit, this monitor operates with upper limit (5.10) or lower limit (0.70).

  • Page 36: F5 Selection Of Power Saving Mode

    ■[F 5] Select power saving mode Power saving mode is selectable. When the product is left for 30 seconds without any operation, it’s shifted to power saving mode. In the default setting, power saving mode is OFF (normal mode). (During operation, the operation indicator is turned on or turned off corresponding to decimal points and output conditions.) <Operation>...

  • Page 37: F6 Setting Of Security Code

    ■[F 6] Set security code input Pin number can be entered during the key-lock state. See page 40 for key lock function. In the defaut setting, security code entry is not necessary. <Operation> Press the button at function selection mode to display [F 6]. Move on to set secret code input.

  • Page 38: F95 Selection Of Flow Indication

    ■[F95] Selection of flow indication Flow range or flow indication unit can be selected. To use flow indication mode, select the flow range and flow unit with this function mode before setting the function of [F1], [F2], [F4]. <Operation> Press the button in function selection mode to display [F 95].

  • Page 39: F99 Reset To The Default Setting

    Selection of flow unit [Uni] and set value are displayed by turn. Press the button to select flow range. Press the button to set Return to the function selection mode. Setting of [F95] flow indication moe completed Fllow unit selection is available only for unit selection type. When the unit is changed, use unit seal included in accessories.

  • Page 40: Other Setting

    Other Setting ●Standard value offset function If the displayed value can be 1.00 due to the deviation in each product, the displayed value can be forcibly changed to 1.00 for PFMV505, 510 and 530. For PFMV505F, 510F and 530F, the forcibly changed value will be 3.00. Press the buttons together for 1 second or longer under the condition with no flow.
  • Page 41 ●Key Lock A wrong operation performed unintentionally such as change of set value can be prevented. If the button operation is performed while key lock setting is being performed, [LoC] is indicated for approx. 1 second. <Operation-Without secret code input> (1) Keep pressing the button for 5 seconds or longer in the measurement mode.
  • Page 42 (3) When the button is pressed, the input of security code is asked. For how to input the security code, refer to [How to input and change the security code] on page 42. (4) If inputted security code is correct, the display changes to [UnL], and pressing one of buttons releases key lock, and returns measurement mode.
  • Page 43 ●How to change the security code In the defaut setting, the security code is set to [000], but can be changed to optional one. <Operation> (1) After the lock setting is finished (page 40), perform all three steps in the unlock setting procedure. (page 40,(3)).
  • Page 44 ●Indicated content check function This is the function to check if indicated content during measurement mode is voltage or flow rate. This function is available only when flow indication is selected with function mode [F95]. <Operation> Press the button and release it within 1 second to indicate the flow range for 0.5 second which is selected by function mode [F95].

  • Page 45: Troubleshooting

    Troubleshooting ●Troubleshooting If operation failure happens at a product, please seek a cause of your trouble with the following chart by tracing failure applicable to your case. If the cause you reached seems not to be applicable to your case, and the product operates normally after replacing the failed one with a new one, the product would be broken.
  • Page 46 Fault Status Possible cause Item to check Countermeasure Mounting Check that the mounting Mounting direction of the direction of the direction of the product and the product, analog signal output product and analog voltage output direction direction and fluid flow signal output are the same as the flow direction should be the same.
  • Page 47 Fault Status Possible cause Item to check Countermeasure Check if there is supply pressure fluctuation or Install a tank to reduce the pressure pulsation due to the pressure fluctutation. Flow is pulsing Wrong Indication/voltage is characteristics of the Change the pressure source to display not stable compressor or pump acting as...

  • Page 48: Error Indication

    ■Error indication function This function is to display error location and content when a problem or an error occurs. Error Name Error Display Error type Troubleshooting Input voltage (=flow rate) exceeds the Reduce input upper limit. voltage (=flow rate) Input voltage Input voltage (=flow rate) is less than the Increase input Error...

  • Page 49: Specification

    Specification ■Specifications Model Series PFMV3□□ Applicable sensor Series PFMV505(F), PFMV510(F), PFMV530(F) Voltage 1.00 to 5.00 V Rated range 0.000 to 0.500 L/min 0.00 to 1.00 L/min 0.00 to 3.00 L/min Flow -0.500 to 0.500 L/min -1.00 to 1.00 L/min -3.00 to 300 L/min 0.70 to 5.10 V: The voltage under 0.70 V is display as"LLL"...
  • Page 50 Model Series PFMV3□□□ Display accuracy ±0.5% F.S. ± 1 digit or less. 3+1/2-digit, 7-segment LED 2-color display (Red/Green) Updated cycle: 10 Display method times/sec OUT1: llluminates when output is turned ON (Green), Status LEDs OUT2: llluminates when output is turned ON (Red). No-voltage input (Reed or Solid state), LOW level input 5 msec or more, External inout (Auto-shift input) LOW level 0.4 V oe less...
  • Page 51 -50- No.PF##-OMN0005...
  • Page 52 Output characteristics (Voltage display) (Flow display) Part number Min.rated flow Max.rated flow PFMV505 0 L/min 0.5 L/min PFMV510 0 L/min 1.0 L/min PFMV530 0 L/min 3.0 L/min PFMV505F -0.5 L/min 0.5 L/min PFMV510F -1.0 L/min 1.0 L/min PFMV530F -3.0 L/min 3.0 L/min Cable specifications: Power supply/Output connector (ZS-28-A) Nominal cross section area...

  • Page 53: Characteristic Chart

    Characteristic chart •Refer to catalog for details of the flow characteristic. -52- No.PF##-OMN0005...

  • Page 54: Dimensions

    ■Dimensions PFMV3 -53- No.PF##-OMN0005...
  • Page 55 Revision history URL http://www.smcworld.com 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 102-0021 Japan Tel:+81 3 5207 8249 Fax:+81 3 5298 5362 Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2010 SMC Corporation All Rights Reserve No.PF##-OMN0005...
