○Battery low
When the battery voltage lowers, "L" will be displayed. The display will be done in a different way
depending on how much battery is left.
Display
The battery is low.
L (Flashing)
Prepare for replacement with a new one.
The battery is very low.
L (Solid on)
Replace with new battery immediately.
○Indicated digit change function
The minimum indicate digit is changed depending on charged potential.
<Display example>
±1 to ±20 kV
Min. indicate unit: 0.1 kV
Content
0 to ±0.99 kV
Min. indicate unit: 0.01 kV
-13-
No.SFOD-OML0002-A
