Jaypro Sports LC-5A Quick Start Manual

18
7
10
17
5/16" FLAT WASHER
(SUPPLIED w/ GOAL)
5/16" FLAT WASHER
(SUPPLIED w/ GOAL)
5/16"-18 x 2 1/2" BOLT
(SUPPLIED w/ GOAL)
3
9
5/16"-18 FLANGE NUT
(EXTRA HARDARE SUPPLIED w/ GOAL)
PLEASE NOTE:
1) FOR SAFE OPERATION AND CONTINUED
HIGH PERFORMANCE FROM THIS EQUIPMENT,
INSPECTION AND MAINTENANCE MUST BE
PERFORMED BEFORE EACH USE
2) USE OF THIS EQUIPMENT OTHER THAN
INTENDED MAY BE HAZARDOUS.
3) ALTERATION OR MODIFICATION OF EQUIP-
MENT MAY BE HAZARDOUS. FOR REPAIR OR
REPLACEMENT, PLEASE CALL YOUR DEALER
1
11
9
4
DO NOT ALLOW ANY PLAYER TO
HANG FROM OR SLAM DUNK ON
THIS GOAL. THIS IS DANGEROUS
AND THE EXTRA WEIGHT MAY DAMAGE
THE EQUIPMENT.
(NET SUPPLIED w/ GOAL)
2
6
5
8
11
16
USE THIS ANCHOR POSITION FOR 7 FT HEIGHT
USE THIS ANCHOR POSITION FOR 7 1/2 FT THRU 9 FT HEIGHT
CAUTION
JNY-4HP
12
5/16" FLAT WASHER
(SUPPLIED w/ GOAL)
MODEL NUMBER:
PRODUCT NAME:
ADJUSTABLE LITTLE CHAMP
DATE: REV:
5/5/2020
5/16"-18 x 2 1/2" BOLT
(SUPPLIED w/ GOAL)
CHECKED BY:
LC-5A WVB
DRAWN BY: SHEET:
A Moune T. 1 OF 4
