Comeup DH-300 Manual

Heavy duty hoist
Hide thumbs Also See for DH-300:
1
2
3
4

Advertisement

Table of Contents

Introduction

Feature

Lifting capacity:
Lifting height:
Lifting speed:
Motor output:
Brake:
Control:

Unpacking

．Hoist assembly.................................................................... 1pc
．Control ass'y........................................................................ 1pc
．Pendant switch PB-306 w/cord 0.75 mm x 3C x 4.4m................... 1pc
．Wire rope 4.8 mm x 12 m w/safety hook..................................... 1pc
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless hoist operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the followings information:
．Hoist PN
．Serial number
．Part description
．Replacement part number
．Quantity for each part
300 kg wire rope top layer
12 m
5 M/min
300 W x 35 A at DC12V
Electromagnetic and mechanical ratchets
Pendant switch powers the hoist
Heavy Duty Hoist
DH-300
Model:
PN: 752639 12V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comeup DH-300

Summary of Contents for Comeup DH-300

  • Page 1 Heavy Duty Hoist DH-300 Model: PN: 752639 12V Introduction Feature Lifting capacity: 300 kg wire rope top layer Lifting height: 12 m Lifting speed: 5 M/min Motor output: 300 W x 35 A at DC12V Brake: Electromagnetic and mechanical ratchets...
  • Page 2 Installation Before using the hoist, make sure all electrical components have no corrosion or damaged; the environment should be clear and dry. Wire rope replacement ． Insert the wire rope into the hole of drum and fix it with a P. T. screw, then press the "UP"...
  • Page 3 Warning ． The hoist is not intended to be used in any manner for the movement or lifting of personnel. ． The lifting capacity shown is based on the top layer of rope on the drum. ． The rope winding on the drum shall remain 5 wraps from the drum. Parts List Ver:0 Item...
  • Page 4 Hoist Assembly...
