7. ANNEX

Frame height
29mm
30mm
31mm
32 mm
33 mm
34 mm
35 mm
36 mm
37 mm
38 mm
39 mm
40 mm
41 mm
42 mm
43 mm
44 mm
45 mm
46 mm
47 mm
48 mm
49 mm
50 mm
51 mm
52 mm
Applying EPDM sealing tape
1. Cut with a knife the self-adhesive EPDM sealing tape into pieces
of about 9 cm. Then pull the yellow strip from the tape.
2. Stick the EPDM sealing tape onto the underside of the mounting
brackets. The 2 holes of the mounting bracket should be completely
covered.
Securing vertical profiles (with landscape setup)
Secure the vertical profiles to the top with the RVS hexagonal
bolt M8 x 20 and hex flange bolt M8.
Rev. 10.06.15
End clamp
MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
CFA
CFA
CFB
CFB
CFA
CFA
CFB
CFB
CFA
CFA
CFB
CFB
CFA
CFA
CFB
CFB
CFA
CFA
CFB
CFB
CFA
CFA
CFB
CFB
1
9 cm
1
Screw length
55 mm
55 mm
55 mm
55 mm
60 mm
60 mm
60 mm
63 mm
63 mm
63 mm
63 mm
63 mm
70 mm
70 mm
70 mm
70 mm
70 mm
70 mm
75 mm
75 mm
75 mm
75 mm
75 mm
75 mm
2
2
