Preface

This manual describes the installation and operation of the following oscilloscopes:
TBS2072B

Key features

This oscilloscope can help you verify, debug, and characterize electronic designs. Key features include:
• Bandwidth variants 50 MHz, 70 MHz, 100 MHz and 200 MHz. Ability to upgrade to higher bandwidth for 70 MHz and
100 MHz units post purchase.
• 2 channel and 4 channel models
®
• TekVPI Versatile Probe Interface supports active voltage and current probes for automatic scaling and units
• Large 9 inch (228 mm) 7 inch WVGA wide-screen color display
• Sample Rates of 1 GS/s on all Channels (2 GS/s on half Channels)
• Up to 5 million points 20K points record length on every channel
• Up to 10,000 5,000 waveforms/second capture rate
• Supports 32 automated measurements
• Edge, Runt and Pulse Width triggers
• Automated Search and Mark offers the ability to quickly search for all events of interest within the acquisition.
• FFT analysis for waveform spectrum analysis
• Wi-Fi (with optional TEKUSBWIFI dongle) and Ethernet for remote operation and programming
®
• e*scope website, accessed by typing instrument IP address into a Web browser, provides remote UI control and SCPI
command support
• USB 2.0 Host ports for quick and easy storage of screen images, instrument settings, and waveforms to USB flash
drives; installing firmware updates; and loading waveforms and settings from saved files
• USB 2.0 Device port for direct PC control of the oscilloscope using TekVISA connectivity, and other remote connectivity
tools that support USBTMC
• Scope Intro provides a built-in overview of oscilloscope concepts and an introduction to the TBS2000B TBS1000C
controls and features
• HelpEverywhere™ displays graphics and short text descriptions when you access the menus for most oscilloscope
settings
• Courseware function provides on-oscilloscope teaching instruction, with hundreds of courses available on the Tektronix
Education Web page and the ability to easily create courses specific to your education needs

Bandwidth options for TBS2000B

These bandwidth options for TBS2000B Oscilloscope enable you to upgrade the bandwidth of a purchased oscilloscope to
a higher bandwidth.
Licence
BWU2-70T100
BWU2-70T200
BWU2-100T200

Conventions used in this manual

The following icons are used throughout this manual.
TBS2000B Series Oscilloscopes User Manual
TBS2074B TBS2102B
Description
BW upgrade from 70 MHz to 100 MHz
BW upgrade from 70 MHz to 200 MHz
BW upgrade from 100 MHz to 200 MHz
