Flush-Mounting the Unit

1. Slide seal over display.
2. Slide the display through the cutout.
3. Fasten backing plate to the display using the 6 short 8-32 screws. Torque to 10 inch-
pounds.
4. Install the long 10-32 screws into the backing plate with locking nuts between the
display and the plate.
5. Hand-tighten the screws to draw the display tight against the panel.
6. Torque to 3 inch-pounds then tighten locking nuts.

Available Accessories for the PV700

The following PV700 accessories are available through Enovation Controls:
Part Number
78700667 PV700, Standard
78090098 Programming Kit
78051451 Kit, Mounting Bracket, PV700
78090069 Harness, PV750/PV700 Conversion, Power/CAN
Description Order Details
Display
Accessories
Service
