Configuration Information

Follow these steps to download a custom configuration to the PV700 display:
Step
1 Turn off the display.
Insert the USB drive that contains the new configuration file into the display's
2
attached USB pigtail.
3 Place a magnet into the notch shown here on the upper middle side of the
back of the display:
4 Power the display back on, continually holding the magnet in place.
5 Remove the magnet when the display shows the utility for loading new software.
6 Touch the up or down arrow keys on the screen until the appropriate configuration file
from the USB to be loaded into the display is shown on the screen.
7 Press the right arrow/green arrow key on the screen twice to load the selected
configuration.
8 Once completed, the unit will reboot into the loaded application.
Action
