6. MAIN MENU: Settings Menu (... cont)
6.26 Routes & Tracks
(MAIN MENU → Settings → Routes & Tracks)
This screen contains the configurations for route
and track simplification degree. This is an algorithm
that the device uses to remove the many needless
waypoints from a track when converted to a route.
By default this is set to '005' which should be fine
in most cases. In this setting, the algorithm will
check to see how many waypoints can be removed
in every 5 meter length of the track without losing
the shape of the track. If you are finding too many
straight lines in routes created from tracks, you can
lower the simplifcation degree. Or if there are too
many waypoints, increase the simplication degree.
Alternatively, change the simplification degree to
'000' to turn it off and not remove waypoints. You will
find routes that have not been simplified slow to load
and may cause freezing on the device.

6.27 Button Control

(MAIN MENU → Settings → Button Control)
The 4 side-press or 2 front-press buttons on
the unit enable one-handed operation and are
multifunctional, with variable keys depending on
the screen displayed. You are able to customize the
operating of your unit and tailor it to fit your needs,
i.e. how many clicks you want the buttons to operate
with, and whether you are right/left handed.
Map Buttons Activation -
This function applies
to the GPS MAP or PLANNING screens. Use the
rocker pad to toggle between settings.
Software v3.13.11
One Click (Always show): one click activates button
instantly. The screen button icons will stay displayed
always. Useful for new new users.
One Click (Hide): Pressing a button will immediately
activate the selcted funtion. For Pan and Zoom,
the screen button icons will NOT
function has been completed. This setting is useful
for experienced users, who are already familiar with
the button layout and require the screens to react as
quickly as possible.
Two Clicks:
This setting is useful for new users
who wish to see the "soft" keys before activating
a particular function. After press a key once - the
"soft key" on-screen icon will show - and then a
second press is required to initial the function. After
the function is completed, the icons will disappear,
allowing the maximum map visability.
Press Done to return to SETTINGS MENU
Please Note: The '"Always Show" and Two Click'
operations are particularly useful for beginners, as they
will be able to see the gray icon that appears on the
screen before the button takes the intended action.
Left / Right Handed Setting -
Use the rocker pad, moving left / right to toggle
between Right Handed and Left Handed
Press Done or centre press the rocker pad to return
.
to SETTINGS MENU
Pressing the Default button restores the factory
settings.
55
show after the
.
operation.
