6. MAIN MENU: Settings Menu (... cont)

6.14 GPS Settings

(MAIN MENU → Settings → GPS settings) `
Position Display Format
(i.e. grid reference format)
Use the rocker pad, moving left/right to select from
DDD.DDDDDD (Degrees decimal)
DDD MM.MMM (Degrees, minutes decimal)
DDD MM SS.S (Deg, Mins, Secs decimal)
British Grid.
OSGB (Ordnance Survey GB);
German Grid;
UTM (Universal transverse Mercator);
MGRS (Military Grid Ref System);
GARS (Global Area Reference System);
CH1903 / LV03 Swiss Grid;
Swedish Grid RT90;
French Grid Lambert 2E;
French Grid Lambert 93;
Irish Grid ITM;
Irish Grid IG;
Pakistan MG;
New Zealand TM;
Maidenhead
PSAD56 21N (Guyana)
Press Done or centre press the rocker pad to return
to SETTINGS MENU.
OSGB grid references are given to 10 figures. If you
are working to 6-figure grid references, set the last 2
digits of each number set to 0.
Software v3.13.11
Use GPS Compass
The Active 20 has an electronic compass (good
when stationary) and a GPS compass (good when
in motion), and switches between the two at a
preset speed. In this setting you are able to select
the speed at which the GPS compass overrides
the electronic compass. The GPS compass is more
accurate the faster you go.
Use the rocker pad, moving left/right to select from
Never, then from 1 kph/0.5 mph to 16 kph/10 mph.
Press Done or centre press the rocker pad to
return to SETTINGS MENU.
Satellite Constellations
GPS, GLONASS, GALILEO
This is the default & recommended setting for best
all-round performance, allowing the GPS unit to
access all the major global satellite networks.
GPS Only
Specifiaclly some users may want to use only GPS
(American) satellites for thier global navigation. In
this mode the GPS module uses slightly less power,
but occasionally the GPS location may be worse
under certain circumstances than using GPS,
GLONASS & GALILEO.
Test Mode (origin)
In this mode a simulated GPS signal is given to the
unit and it starts a pseudo track from the Origin (lat
0, Long 0). In certain circumstances this is used for
software development & testing. Please Note:
mode is not suitable for outdoor activity navigation.
47
Test Mode (UK)
In this mode a simulated GPS signal is given to the
unit and it starts a pseudo track from a position in
the West of England. In certain circumstances this
is used for software development & testing.
Note: this mode is not suitable for outdoor activity
navigation.
Demo Modes / leatherhead Mode / Active Route
These modes are typically used by retailers wishing
to have the unit periodically reset to defaul settings
and display a moving map on the screen and
developers testing the device for faults.
Off
In this mode the GPS signal is turned Off.
this
Please
