6. MAIN MENU: Settings Menu (... cont)

6.12 Data - 4 Box Layout (upper)

(MAIN MENU → Settings →
4 Data Box Layout: upper)
For both the Upper Left Box and the Upper Right
Box:
• Use the rocker pad, moving left/right to select the
desired option.
• Press Done or centre press the rocker pad to
return to SETTINGS MENU.
The data options are listed below and are the same
for both 2 data box and 4 data box layouts.
Pressing the Default button restores the factory
settings for this item:
Data boxes are shown on the GPS MAP
To reach the GPS MAP screen from the
MENU, press Map (front left button).
On the GPS MAP screen, use the lower left side
button to toggle between having 2 data boxes, 4
data boxes or none.
Software v3.13.11

6.13 Data - 4 Box Layout (lower)

(GPS MAP → MAIN MENU → Settings →
4 Data Box Layout: lower)
For both the Lower Left Box and the Lower Right
Box:
• Use the rocker pad, moving left/right to select the
desired option.
• Press Done or centre press the rocker pad to
return to SETTINGS MENU
The data options are listed below and are the same
for both 2 data box and 4 data box layouts.
Pressing the Default
factory settings:
screen.
SETTINGS
.
button restores the
43
Upper Data
box selections
Lower Data
box selections
