Enforcer 32-WE Wireless Setup Manual
9.4.1 Technical Specifications
Input Configuration: Type: Normally Closed.
Lens/Detection
KX12DT-WE: 12m volumetric coverage, 60 zones (30 positive, 30 negative), 7 planes, 85˚
(2.4m mounting height)
KX10DTP-WE: 10m volumetric coverage, 50 zones (25 positive, 25 negative), 5 planes,
85˚(2.4m mounting height)
KX12DQ-WE: 12m volumetric coverage, 60 zones (30 positive, 30 negative) 7 planes,
85˚(2.4m mounting height)
KX10DP-WE: 10m volumetric coverage, 50 zones (25 positive, 25 negative), 5 planes,
85˚(2.4m mounting height)
KX25LR-WE: 25m long range coverage, 46 zones (23 positive, 23 negative) 6 planes, 17˚(2.4m
mounting height)
KX15DC-WE: 15m curtain coverage, 24 zones (12 positive, 12 negative), 6 planes,
20˚(2.4m/4m mounting height)
Detection Speed: 0.3- 3.0m/s
Sensitivity: High or Low
Battery: 1 x 3.0V CR123A. Threshold: 2.5V +/- 5% at 25°C.
(Battery KX12DT & KX10DTP: 2 x 3.0V CR123A. Threshold: 2.5V +/- 5% at 25°C)
Life: Up to 2 Years
Wireless: Transmission Frequency: 868MHz, FM Transceiver Narrow Band
Transmission Method and Range: Fully encrypted rolling code/1.6km free space
Materials and Environment
Colour and Casing: White. 3mm ABS
Indication: LEDs (Signal, Alarm, Tamper)
Temperature Compensation: Advanced Automatic
Temperature: Storage:-20°C to 50°C. Certified:-10°C to 40°C. Nominal:-10°C to 50°C
Dimensions (H x W x D): 117 x 69 x 50mm (KX12DT-WE & K10DTP-WE = 117 x 69 x 59mm)
Compatible with the Enforcer 32-WE, PCX and EURO control panels (EURO-ZEM32-WE/PCX-
RIX32-WE only).
Do not partially or completely obscure the detectors field of vision
NOTE: The KX brackets are optional.
