- Page 1 Digital monochrome / color HDTV (1080p) CMOS camera CV-A20 CL CV-A80 CL Operation Manual Document Version: 1.0 Camera Revision: 0 Copy right © 2007 JAI All rights reserved...
- Page 2 CV-A20 CL / CV-A80 CL Special Caution When a Camera Link cable is connected to the camera, please do not excessively tighten screws by using a screw driver. The Camera Link receptacle on the camera might get damaged. For security, the force used to tighten screws is less than 0.291 Newton Meter (Nm).
-
Page 3: Table Of Contents
7.2. RS-232C control ..................20 7.3. Save and Load Functions................21 7.4. CV-A20CL / CV-A80CL Command List ............. 21 Camera Control Tool for CV-A20CL/CV-A80CL ............. 24 8.1. Camera Control Tool Interface ..............24 8.2. Camera Control Tool Bar ................24 8.3. -
Page 4: General
Bayer mosaic color sensor. The sensor has a 2/3 inch format and 16:9 aspect ratio. Total number of pixels is 2,112 (H) x 1,188(V). The CV-A20CL/CV-A80CL operates at 60 frames per second with full resolution and at higher frame rate by using the window-scanning mode. -
Page 5: Locations And Functions
CV-A20 CL / CV-A80 CL 4. Locations and functions ⑥ H I R O SE 12pi n C onnect or ② ③ Power/TRIG ⑤ ① ④ C am er a Li nk C onnect or C - M ount ⑥ 1. -
Page 6: Pin Configuration
CV-A20 CL / CV-A80 CL 5. Pin configuration 5.1. 12-pin multi connector Type: HR10A-10R-12PB Use the part number HR10A-10P-12S for the cable side Name Note +12V Power IRIS VIDEO Video signal for Auto Iris Lens RS-232 C (default setting is CL serial communication) Strobe out Exposure Enable (Active low) Trigger... - Page 7 CV-A20 CL / CV-A80 CL Camera amera Link Cable Camera Signals 2tap Camera Link Port/ 8bit 10bit 8 bit 10 bit Signal Output output Connector Pin Port A0 DA0(LSB) DA0(LSB) Tx0 Signal Port A1 DA1 Port A2 DA2 Tx27 Port A3 DA3 Pair 1 Port A4 DA4 Pair 2...
-
Page 8: Input And Output Circuits
CV-A20 CL / CV-A80 CL 5.3. Input and output circuits In the following schematic diagrams, the input and output circuits for video and timing signals are shown. 5.3.1. Iris video output This signal can be used for lens iris control in Continuous mode. -
Page 9: Functions And Operations
6.1.1. Formatted Odd and Even Interleaved output Although the CV-A20CL CMOS sensor operates at 148.5MHz, the output pixel rate is a half of that, 74.25MHz due to using the Formatted Odd and Even Interleaved output. Odd pixels of lines and even pixels of lines are output respectively as shown the below. - Page 10 CV-A20 CL / CV-A80 CL Fig.10. Transition of each part of Snap-shot trigger operation Ext. Trig FVAL Strobe out Exposure on Sensor Exposure Line #1 Exposure Line #1125 Data Output 1125 Sensor Readout Stop Period Note: The above drawing shows the case of "Strobe Delay Time = 0". Important Note: The CMOS sensor does not have a mechanism that allows pixels to be reset at one time, and is therefore accumulating and reading out continuously.
-
Page 11: Window Scan
The CV-A20CL/CV-A80CL permits "Windowing" in the vertical direction. This reduces the number of lines being read out, thus increasing the frame rate. For the CV-A20CL the increment is 1 line and for the CV-A80CL the increment is 2 lines. Depending on the number of lines selected the frame rate can be varied from 60 fps for full line read out to 1125 fps. -
Page 12: Frame Rate For Window Scan Mode
CV-A20 CL / CV-A80 CL 6.1.4. Frame rate for Window Scan Mode The frame rate is calculated as follows: Frame frequency = 1L [67,500] divided by (Blanking Period [45] + windowing scan period [lines]) For instance, in the case that the vertical window is set at 540 lines the frame frequency is 67,500 ÷... -
Page 13: Image Sensor
CV-A20 CL / CV-A80 CL Command SM: Shutter mode SM=0 Preset shutter SM=1 Programmable exposure Command SM=0 Preset shutter 0=OFF(1/60) 1=1/120 2=1/250 3 =1/500 4=1/1000 5=1/2000 6=1/5000 7=1/ 10,000 8=1/20,000 Command SM=1 Programmable exposure The exposure time can be set in 1 LVAL unit in the range from 2LVAL to 1,125 LVAL. -
Page 14: Video Output Timing Via Camera Link
CV-A20 CL / CV-A80 CL 6.2.2. Video output timing via Camera Link Definition FVAL : Frame Valid is defined HIGH for valid lines. LVAL : Line Valid is defined HIGH for valid lines. DVAL : Data Valid is defined HIGH when data is valid. EEN : Enable Exposure LVAL Period (Continuous, Full Frame) 1ck：... -
Page 15: Inputs And Output Signals
CV-A20 CL / CV-A80 CL 6.3. Inputs and output signals 6.3.1. External trigger - Input The external trigger can be input via pin 10 on 12-pin Hirose connector or through Camera Link connector. At the 12-pin connector the input level should be TTL or 4.0Vp-p ± 2.0Vp-p from a 75-ohm source. Two software commands allow the selection of trigger input (TI) and trigger polarity (TP) Command TI Trigger input... -
Page 16: Operation Modes
SM=0 or 1 Window scan select "Full" or "Window" WS=0 or 1 If used Window scan start WY=0 to 1079 for CV-A20CL WY=0 to 1078 for CV-A80CL Window scan height WH=1 to 1080 for CV-A20CL WH=2 to 1080 for CV-A80CL... - Page 17 TP = 0 or 1 Window scan select “Full” “Window” WS=0 or 1 If used Window scan start WY=0 to 1079 for CV-A20CL WY=0 to 1078 for CV-A80CL Window scan height WH=1 to 1080 for CV-A20CL WH=2 to 1080 for CV-A80CL...
-
Page 18: Widowing Timing Chart
CV-A20 CL / CV-A80 CL EXT TRIG STROBE OUT FVAL * Ａ Full scan LVAL Window scan DVAL DATA OUT Trigger Unacceptable Period Fig.21. Minimum Trigger period The following equation is used for calculating the minimum trigger interval. (Strobe delay 0 + Strobe Delay Time) + Strobe out period + (0 to1L) + 38L + 9L(OB) + Effective period + 2L + 1L Whereby, Strobe delay 0 is inherent delay which is fixed at 35 clk ±... -
Page 19: Mode And Function Compatibility Matrix
CV-A20 CL / CV-A80 CL LVAL Period (Continuous, Windowing) 1ck： 74.25MHz(13.47ｎ S) 1 LVAL Period 1100c k 140c k LVAL FVAL H W idtn DVAL DAT A OUT ST ROBE OUT Fig.23. Horizontal timing, Window scan 6.4.4. Mode and function compatibility matrix Shutter Windowing Strobe... - Page 20 CV-A20 CL / CV-A80 CL and -1 for -2dB. Command GAF Gain Fine level This command sets the gain level with a fine granularity. Command BL Offset / Black level This can change the offset / black level (set-up) level manually. Command BRMO Black Reference (for continuous mode) This can select Auto or Manual for black level control.
-
Page 21: Configuring The Camera
7. Configuring the Camera 7.1. Switch settings The CV-A20CL/CV-A80CL can communicate by serial communication via the Camera Link connector or via RS232C in the 12-pin Hirose connector. The Baud Rate is fixed at 9600 bps. Switch SW2 inside the camera is used to select which way the serial communication is set up. -
Page 22: Save And Load Functions
This command will store the actual camera settings to 1 of the 3 user area in the camera EEPROM. EEPROM Area. EA. The camera returns the last used user area number. 7.4. CV-A20CL / CV-A80CL Command List Command Name Format... - Page 23 (Set in step 1; 1L=14.815us) TR=1. D - Scan Format and video output Window Scan WS=[Param.]<CR><LF> 0=Full Frame Select WS?<CR><LF> 1=Window Scan CV-A20CL 0 to 1079 WY=[Param.]<CR><LF> 1 line step 2 Window Scan Start WY?<CR><LF> CV-A80CL 0 to 1078 2 lines step...
- Page 24 CV-A20 CL / CV-A80 CL -3 to 12 GA=[Param.]<CR><LF> (-1=-6dB,-2 = -3dB, -1 = -2dB , 3 Manual Gain Level GA?<CR><LF> 0=0dB, 1=1dB, … 12=12dB) PG=[Param.]<CR><LF> 0 = OFF ( Main Gain ) 4 Pixel Gain ON/OFF For CV-A80 only PG?<CR><LF>...
-
Page 25: Camera Control Tool For Cv-A20Cl/Cv-A80Cl
CV-A20 CL / CV-A80 CL 8. Camera Control Tool for CV-A20CL/CV-A80CL The Camera Control Tool for Windows 2000/XP can be downloaded from www.jai.com. The control tool contains a camera control program and a developer's kit for integrating the control tool in your own software. For the integrator and experienced user, the Camera Control Toll is much more than a program with a window interface. -
Page 26: Communication Window
CV-A20 CL / CV-A80 CL It is possible to download updated operation manuals from the "downloads" section at the JAI website: http://www.jai.com An updated manual can be saved in the (default) folder address mentioned above. It will then automatically be included in the list of help files. - Page 27 CV-A20 CL / CV-A80 CL the ’Serial Port’ list box or click the ‘Auto’ button to search for a camera on communication port 1 to 16. The Serial Port list box and the Auto search button are only active when COM-ports is selected. Camera Link communication: The ’CL Manufacturer/COM-ports’...
-
Page 28: Camera Control Window
Click the ‘Get Area’ button to read the power up settings area number. Camera Control Window 8.5. The Camera Control Window contains the fundamental camera setting functions. It is possible to set the shutter mode, Trigger mode, scan format, gain control and black setting. For CV-A20CL for CV-A80CL... -
Page 29: Using The Camera Control Tool
3. It is possible to work with the Camera Control Tool when the camera is online and when the camera is offline. 4. The newer JAI cameras always start up with the last used user area (but for some old models it will start up with the last saved user area.) 5. -
Page 30: External Appearance And Dimensions
CV-A20 CL / CV-A80 CL 9. External Appearance and Dimensions Fig.26. Dimensions... -
Page 31: Specifications
CV-A20 CL / CV-A80 CL 10. Specifications 10.1. Spectral response Wavelength nm Fig. 27. Spectral response for monochrome CMOS Fig.28. Spectral response for Bayer Color CMOS (Shown without 700 nm IR-cut filter) -
Page 32: Specifications Table
CV-A20 CL / CV-A80 CL 10.2. Specifications Table Specification CV-A20CL CV-A80CL Image sensor Monochrome CMOS Bayer mosaic color CMOS Scan system Rolling shutter Frame rate 60 frames / sec. (at full frame) Pixel Clock 2 x 74.25 MHz (interleaved odd and even pixels) Horizontal Frequency 67.50 kHz (2200H) x 6.73ns=14.815μs... -
Page 33: Appendix
CV-A20 CL / CV-A80 CL 11. Appendix 11.1. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera. -
Page 34: User's Record
Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification. - Page 35 CV-A80CL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
