5.2.5.2

Arc length

When required, the arc length (welding voltage) can be adjusted for the welding task in hand by +/– 9.9 V.
5.2.5.3

Arc dynamics (choke effect)

This function can be used to adjust the arc between a narrow, hard arc with deep penetration (positive
values) and a wide and soft arc (negative values). In addition, the selected settings are displayed with
signal lights below the rotary knobs.
5.2.6

Copy JOB (welding task)

099-5TLPXQ-EW501
29.01.2021
7s
Functional characteristics
Figure 5-10
Figure 5-11
3s
Figure 5-12
MIG/MAG welding
