► CONNECTIONS

► TUNER (IF)
Connect (DVB-T2) an outdoor VHF/UHF antenna or cable
RF IN (T2)
► LNB-IN (DVB-S2)
ANT 75Ω S2
► HDMI1, HDMI2 Digital connection
Connect an HDMI cable from an external A/V equipment.
Some devices such as DVD player require HDMI signal to be set to output in the device's
settings.
Please consult your device user manual for instructions. Please note that the HDMI
connector provides both video and audio signals, it's not necessary to connect an audio
cable.
• Press [SOURCE] button, when the list of Input Source appears, press [▲/▼] to select
the source [HDMI], then press [OK] to connect.
Connect (DVB-S2) satellite dish or Sat cable connection.
15
VIVAX
SAT Antenna
SAT cable socket
