5.
Place the stanchion on the storage unit, with their
tube holes facing inward (5a). Make sure the pencil
marks are aligned with the stanchion plate locating
notches (5b). Mark all hole locations with a pencil for
both stanchions (5c). Remove and drill 1/8" diameter
pilot holes through the laminate surface only (hole
depth only a 1/4") (5d). Secure each stanchion with
eight (8) 3/4" long flat head screws provided (5e).
NOTE: Make sure the tube holes are facing inward.
5b
5a
WARNING:
5c
DO NOT drill
deeper than 1/4"
TUBE
HOLES
5a
5e
5d
