Steelcase Answer Beam Worksurface Manual page 12

®
Install screen assembly to worksurface --
Rear Mount:
1.
Place screen assembly so that the front face of the
screen is offset 1/2" from the rear edge of the worksurface.
2.
Attach screen assembly to underside of Ology desk
worksurface using #10-10 x 1.075" wood screws provided.
(6 screws per stanchion)
1
1/2" Offset
Rear edge of
worksurface
TIP: Use Quick Clamps
to hold screen in place
while installing screws.
2
Page 12 of 12
78540 Rev A
