Install screen assembly to worksurface --
Side Mount:
1.
Place screen assembly so that the front face of the
screen is flush with the side edge of the worksurface.
2.
Attach screen assembly to underside of Ology desk
worksurface using #10-10 x 1.075" wood screws provided.
(5 screws per stanchion)
1
Side edge of
worksurface
Front face of screen is
flush with the side edge
of the worksurface
TIP: Use Quick Clamps
to hold screen in place
while installing screws.
2
