About This Installation Guide

This Installation Guide explains the installation of the Quadro IP PBXs: Quadro2x and 2xi,
Quadro4x and 4xi, Quadro16x and 16xi. The Quadro models differ both in their feature sets
and the number of phone lines and extensions that are supported:
•
Quadro2x offers one phone line (FXO), two phone extensions (FXS) and one
Ethernet WAN port
•
Quadro2xi offers one phone line (ISDN), two phone extensions (FXS) and one
Ethernet WAN port
•
Quadro4x supports two phone lines (FXO), four phone extensions (FXS) and one
Ethernet WAN port - a special version of Quadro4x offers two additional FXO lines
•
Quadro4xi supports one phone line (ISDN), four phone extensions (FXS) and one
Ethernet WAN port
•
Quadro4xa supports two phone lines (FXO), four phone extensions (FXS) and one
ADSL WAN port
•
Quadro4xia supports one phone line (ISDN) four phone extensions (FXS) and one
ADSL WAN port;
•
Quadro4xs supports two phone lines (FXO), four phone extensions (FXS) and one
G.SHDSL WAN port
•
Quadro4xis supports one phone line (ISDN) four phone extensions (FXS) and one
G.SHDSL WAN port
•
Quadro16x supports four phone lines (FXO), 16 phone extensions (FXS) and one
Ethernet WAN port
•
Quadro16xi supports three phone lines (ISDN), 16 phone extensions (FXS) and one
Ethernet WAN port
•
Quadro16xa supports four phone lines (FXO), 16 phone extensions (FXS) and one
ADSL WAN port
•
Quadro16xia supports three phone line (ISDN) 16 phone extensions (FXS) and one
ADSL WAN port
•
Quadro16xs supports four phone lines (FXO), 16 phone extensions (FXS) and one
G.SHDSL WAN port
•
Quadro16xis supports three phone line (ISDN), 16 phone extensions (FXS) and one
G.SHDSL WAN port
The installation procedure for all Quadro IP PBXs is the same. Throughout this Installation
Guide, the standard edition of Quadro4x with two FXO ports is shown as the reference sys-
tem.
This Installation Guide gives step-by-step instructions to provision the Quadro and config-
ure the phone extensions with the Epygi SIP Server. After successfully configuring the
Quadro, a user will be able to make SIP phone calls to remote Quadro devices, make local
calls to the PSTN and access the Internet from devices connected to the LAN.
This Installation Guide neither describes the PBX, Auto Attendant, Call Relay, and Voice
Mail features of the Quadro nor does it provide advanced firewall and VPN configuration in-
formation. For these features, refer to the Administrator's and Extension User's Guides.
