3. Product Specifications

3-1. Specifications

Specifications
Model
Bore size (mm)
Fluid
Operating pressure [MPa]
Ambient and fluid temperature (
Repeatability (mm)
Maximum operating frequency (c.p.m.)
Lubrication
Action
Holding force
Actual value per finger (N)
Opening/closing stroke (both) (mm)
Weight (g)
Auto switch model
Standard for mounting interface
Connector configuration
*The sensing position of the auto switch is fixed to the open end and closed end of the finger.
* When detecting the gripping position of the workpiece, secure the auto switch at the appropriate
position according to the shape of the workpiece.
* For examples of setting auto switch and setting of mounting position of auto switches, please refer to
the JMHZ2 Series catalogue P.15 onwards on our website (www.smcworld.com).
Detecting position of the
open end of the finger
JMHZ2-16D-X7400B
0.1 to 0.7
o
C) -10 to 60
Non-lube
Double acting
O.D.folding
Force (N)
I.D.holding
Force (N)
D-M9P-5
ISO9409-1-50-4-M6
M8 8Pin(female)
6
16
Air
±0.01
120
32.7
43.5
10
430
Detecting position of the
closed end of the finger
