Port Solenoid Valve - SMC Networks JMHZ2-16D-X7400B Operation Manual

4-2. 3 Port Solenoid Valve

Specifications.
Model
Fluid
Ambient and fluid temperature (°C)
Response time (DC) (ms)
Max. operating frequency (Hz)
Lubrication
Mounting position
Impact/Vibration resistance (m/s2)
Enclosure rating
Solenoid Specifications
Model
Electrical entry
Coil rated voltage (V)
Allowable voltage fluctuation
Power consumption (W)
Surge voltage suppressor
Indicator LED
V114-5LU
Air
–10 to 50 (No freezing)
ON: 5 or less OFF: 4 or less
20
Not required
Unrestricted
150／30
Dust proof
V114-5LU
L plug connector(L)
24
-10 to 10%
0.4
[Starting 0.4, Holding 0.1]
Please refer to page 1367 of
the Best pneumatics
catalogue.
LED
12
