2. Parts description of the air gripper

Polyurethane Tubing:
Tubing O.D.φ2
Miniature Fittings:
M-5ALHU-2
One-touch Fittings:
KQ2S04-M5N
Parallel pin：
3x6
ISO9409-1 compliant
flange
M8 8 Pin connector
(female)
)
Auto switch：
D-M9P-5
Air Gripper：
JMHZ2-16D
5
Hexagon socket head
cap screw (M3×7)
Miniature Fittings:
M-5ALHU-2
Metering Valve with
Silencer:
ASN2-M5-X937
Adapter plate
3 Port Solenoid Valve:
V114-5LU
Hexagon socket head cap screw
：M4x25
Parallel pin：
6x10
Hexagon socket
head cap screw：
M6x10
