Tranquility OA (TO) Series
Commercial Vertical
Dedicated Outdoor Air
Packaged Water-Source
Heat Pumps
Installation, Operation
& Maintenance
97B0052N01
Revised: 31 January, 2013

Table of Contents

Model Nomenclature
Vertical Dimensional Data - Model 20-30
Model 20 - 30
Warranty
Revision History
3
4
7
8
9
10
11
12
13
14
15
16
17
18
19
22
23
24
25
27
29
31
33
34
35
37
41
44

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tranquility OA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ClimateMaster Tranquility OA Series

Summary of Contents for ClimateMaster Tranquility OA Series

  • Page 1: Table Of Contents

    Tranquility OA (TO) Series Table of Contents Model Nomenclature General Information Unit Connections and Service Clearances 4-15 Tons Unit Connections and Service Clearances 20-30 Tons Vertical Dimensional Data Model 04 & 05 Vertical Dimensional Model 08 & 10 Vertical Dimensional Data Model 15 Vertical Dimensional Data - Model 20-30 Vertical Dimensional Model 04 &...
  • Page 2 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 This Page Intentionally Left Blank C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...
  • Page 3 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Model Nomenclature EXHAUST MOTOR HP OPTION...

  • Page 4: General Information

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 General Information Safety Warnings, cautions, and notices appear throughout this...
  • Page 5 Promptly fi ll out and ENVIRONMENT. If you must install the DOAS unit outside return the form, and notify ClimateMaster of any damage. you must use an outdoor-rated DOAS unit. ClimateMaster DAMAGE CLAIMS OR SHORTAGES MUST BE FILED...
  • Page 6 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Rigging - ClimateMaster DOAS units are solidly built and CAUTION! can be very heavy. Avoid personal injury and damaged equipment by planning the installation carefully.

  • Page 7: Unit Connections And Service Clearances 4-15 Tons

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Unit Connections and Service Clearances 4-15 Tons Utility Location...

  • Page 8: Unit Connections And Service Clearances 20-30 Tons

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Unit Connections and Service Clearances 20-30 Tons TOV 20-30 Tons Utility...

  • Page 9: Vertical Dimensional Data Model 04 & 05

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional Data Model 04 &...

  • Page 10: Vertical Dimensional Model 08 & 10

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional Model 08 &...

  • Page 11: Vertical Dimensional Data Model 15

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional Data Model 15 c l i m a t e m a s t e r .
  • Page 12 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional Data - Model 20-30 C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...

  • Page 13: Vertical Dimensional Model 04 & 05

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional Model 04 &...

  • Page 14: Vertical With Damper Box Dimensional Data - Model

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical With Damper Box Dimensional Data - Model 20 - 30 C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...

  • Page 15: Vertical Dimensional - Model 08 & 10

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional - Model 08 &...

  • Page 16: Vertical Dimensional - Model 15

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Dimensional - Model 15 C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...

  • Page 17: To Vf/Vd Physical Data Table

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 TO VF/VD Physical Data Table Model Fan motor available H.P.

  • Page 18: Vertical Installation

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Vertical Installation Condensate Piping –...

  • Page 19: Duct System Installation

    R e v. : 0 1 / 3 1 / 1 3 Duct System Installation Duct System Installation - Duct design and installations The total air fl ow of a ClimateMaster 20-ton through should conform to the latest ASHRAE and SMACNA 30-ton system should be checked by measuring the air...
  • Page 20 If this happens, consult the ClimateMaster counterclockwise (to decrease its pitch diameter). To Service Department. Please be prepared with system speed up the blower, turn the outer pulley face clockwise serial and model number.
  • Page 21 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Figure 3: Recommended Duct Design for DOAS Units Recommended Not Recommended...

  • Page 22: Piping Installation

    ClimateMaster will not be responsible or liable for damages from water leaks due to inadequate or a A dedicated circulating pump must be used unless the lack of pressurized leak testing during installation.

  • Page 23: Water Quality Standards

    Rev.: 3/30/12 The ClimateMaster Water Quality Table provides water quality requirements for ClimateMaster coaxial heat exchangers. When water properties are outside of those requirements, an external secondary heat exchanger must be used to isolate the heat pump heat exchanger from the unsuitable water. Failure to do so will void the warranty for the coaxial heat exchanger.

  • Page 24: Electrical Wiring - Line Voltage

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Electrical Wiring - Line Voltage Electrical - Line Voltage - All fi...

  • Page 25: Electrical Wiring - Low Voltage

    Controls Wiring - Many of the controls and sensors in the Duct-Mount Sensor - A duct-mount sensor is normally ClimateMaster Tranquility DOAS units have been factory- used when continuous blower operation is desired or installed and wired. However, you will have to make required.
  • Page 26 Controls Wiring - Many of the controls and sensors in the conduit as wires carrying more than 24 VAC. ClimateMaster Tranquility DOAS units have been factory- installed and wired. However, you will have to make Mounting the Remote Terminal - The remote terminal certain connections in the fi...

  • Page 27: Unit Starting & Operating Conditions

    DOAS unit. THE START-UP REPORT IS REQUIRED FOR 3. Verify that all fi eld wiring matches the ClimateMaster WARRANTY VALIDATION. wiring schematics. Inspect and tighten all fi eld and factory wiring.
  • Page 28 A factory start up does not include installation assistance. The installing contractor is responsible for ensuring that the system is ready for startup when the ClimateMaster representative arrives. When the installing contractor is confi dent the system will be ready, he should contact the ClimateMaster Sales representative to schedule the startup.

  • Page 29: System Operation Modes

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 System Operation Modes Principle of Operation - Tranquility DOAS Units - The Controller Setpoints - To avoid ongoing controller...
  • Page 30 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Tranquility systems equipped with this option are •...

  • Page 31: Service And Maintenance

    NUMBER OF YOUR DOAS UNIT. protection, as contaminated refrigerant and oil can cause severe burns! Routine Maintenance - ClimateMaster DOAS units are designed for years of reliable service. However, like any Mild Burnouts - If the burnout is mild, recover the piece of machinery they require periodic maintenance.
  • Page 32 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Severe Burnouts •...

  • Page 33: Troubleshooting

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Troubleshooting Supply Blower Will Not Run Evaporator Coil Ices Up: Suction Pressure Below 85...

  • Page 34: Appendix

    C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Appendix Figure 9: System Rating Plate Figure 10: Model Numbering Matrix...

  • Page 35: Service Bulletin

    Purchase Order for the second trip must be issued to ClimateMaster. Delays and/or changes to a scheduled commissioning less than fi ve (5) business days in advance may result in additional charges. Commissioning delays on-site of more than 4 hours during commissioning may result in additional charges.
  • Page 36 Company Name: Contact/Salesman Name: A MINIMUM THREE (3) WEEK LEAD TIME IS REQUIRED TO SCHEDULE A DOAS UNIT COMMISSIONING. Submit forms to: Attn: ClimateMaster Technical Service Dept. Fax (405) 745-6058 ClimateMaster 7300 S.W. 44 Street Oklahoma City, OK, 73179 (405) 745-6000...

  • Page 37: Start-Up Report

    IMPORTANT: For warranty validation and activation a copy of this form must be completed for each ClimateMaster DOAS unit and form must be returned to ClimateMaster Technical Service Dept. immediately after completion of commissioning. Warranty shall not be considered valid or active without verifi...
  • Page 38 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Commissioning Report, Tranquility and Genesis Series Heat Pumps, Pg.
  • Page 39 Commissioning Report, Tranquility and Genesis Series Heat Pumps, Pg. 3 DOAS units have warm weather and cold weather modes of operation. Each mode MUST be tested and documented for warranty Validation. For additional information contact ClimateMaster Technical Service Dept. @ (800) 299-9747.
  • Page 40 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...
  • Page 41 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Warranty c l i m a t e m a s t e r .
  • Page 42 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Notes: C l i m a t e M a s t e r Wa t e r - S o u r c e H e a t P u m p s...
  • Page 43 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y Vertical DOAS R e v. : 0 1 / 3 1 / 1 3 Notes: c l i m a t e m a s t e r .
  • Page 44 97B0052N01 ClimateMaster works continually to improve its products. As a result, the design and specifi cations of each product at the time for order may be changed without notice and may not be as described herein. Please contact ClimateMaster’s Customer Service Department at 1-405-745-6000 for specifi c information on the current design and specifi...
