Tranquility
(TS) Series
Models TSD/H/V 006 - 070
60Hz - HFC-410A
INSTALLATION, OPERATION
& MAINTENANCE
97B0075N06
Revised: June 5, 2020
20
®
TS Blower Performance Data - Standard Unit -
TS Blower Performance Data - Units with
ClimaDry
Typical Wiring Diagram - Units with CXM Board
and PSC Fan Motor (Single Phase)
Typical Wiring Diagram - Units with DXM2 Board
and PSC Fan Motor (Three Phase)
Typical Wiring Diagram - Units with CXM Board,
ECM Fan Motor, and MPC (DDC) Controls
Table of Contents
(PSC Motor)
®
®
3
4
6
7
9
10
11
13
14
15
17
19
20
26
27
28
29
30
31
32
33
35
36
37
38
39
40
45
47
49
50
51
®
52
53
55
60
61
62
63
64
Advertisement
Table of Contents
Troubleshooting
Related Manuals for ClimateMaster Tranquility 20 Series
Summary of Contents for ClimateMaster Tranquility 20 Series
-
Page 1: Table Of Contents
Tranquility ® (TS) Series Table of Contents Model Nomenclature - General Overview General Information Unit Physical Data Horizontal Installation Field Conversion of Air Discharge Horizontal Installation Vertical Installation Piping Installation Water-Loop Heat Pump Applications Ground-Loop Heat Pump Applications Ground-Water Heat Pump Applications Water Quality Standards Electrical - Line Voltage Electrical - Power Wiring... - Page 2 C L I M A T E M A S T E R W A T E R - S O U R C E H E A T P U M P S Tranquility 20 ( TS) Series ® R e v .
-
