ClimateMaster Tranquility Technical Manual
Tranquility (thw) water-to-water series
Hide thumbs
Also See for Tranquility:
- Quick start manual (10 pages) ,
- Troubleshooting manual (62 pages)
Related Manuals for ClimateMaster Tranquility
Summary of Contents for ClimateMaster Tranquility
- Page 1 Tranquility (THW) Water-To-Water Series WATER-TO-WATER SYSTEMS SIZES 010 60Hz [10 kW]...
-
Page 2: Table Of Contents
THW Water-To-Water Series Table of Contents Unit Features .................... 2 Wiring Diagram Matrix ..............11 Model Key ....................5 Wiring Diagrams ................12-19 Rated Equipment Performance & Effi ciencies ....... 6 Engineering Guide Specifi cations ..........20 Performance Data ................. 7 Accessories &... - Page 3 ClimateMaster Geothermal Heat Pump Systems Tranquility Water-To-Water (THW) Design Features The THW Series is unlike any other water-to-water heat pump on • High and low pressure service ports on refrigerant circuit. the market today. The large operating map of the scroll compressor •...
- Page 4 THW Water-To-Water Series THW Water-To-Water Series Features Appliance-Style Cabinet for Attractive Look High Temperature Scroll Compressor Fully Insulated Water and Refrigerant Lines Fully Insulated Compressor Section Powder Coated Galvanized Steel Cabinet and Stainless Steel Front Access Panel for Long Life Dual level compressor isolation and discharge muffl...
-
Page 5: Model Key
ClimateMaster Geothermal Heat Pump Systems Model Key T H W 0 1 0 0 0 C S A S S = Standard Series Hydronic Options A = None B = Load Pump W/Expansion Tank Configuration C = Load Pump & Source Pump(S) W = Water-To-Water W/Expansion Tanks Paint Options... -
Page 6: Rated Equipment Performance & Effi Ciencies
THW Water-To-Water Series Rated Equipment Performance & Effi ciencies 60 Hz (IP) Units Ground Loop Heat Pump Ground Water Heat Pump Heating Heating Indoor 86/95°F Indoor 104/113°F Indoor 86/95°F Indoor 104/113°F Model Outdoor 32/27°F Outdoor 32/27°F Outdoor 50/45°F Outdoor 50/45°F Capacity Capacity Capacity... -
Page 7: Performance Data
ClimateMaster Geothermal Heat Pump Systems Performance Data - THW010 Source Load 5.4 GPM 7.3 GPM Power Power °F °F MBtuh MBtuh °F MBtuh MBtuh °F 32.3 1.10 28.6 61.9 32.7 1.10 32.7 59.4 30.0 1.74 27.7 81.1 30.3 1.68 30.3 78.7 27.8 2.41... - Page 8 THW Water-To-Water Series Performance Data - THW010 Source DHW Circuit GPM=3.5 LGPM=5.4 Power Power °F °F MBtuh MBtuh °F MBtuh MBtuh °F 28.2 1.78 22.1 66.1 28.3 1.57 22.9 60.4 27.1 2.15 19.8 85.5 1.80 27.1 1.89 20.7 80.1 6.75 25.6 2.61 16.7...
-
Page 9: Physical Data
ClimateMaster Geothermal Heat Pump Systems Physical Data Model Compressor (qty) Factory Charge HFC-410A (oz) [kg] 88 [2.50] Indoor/Load Water Connection Size FPT (in) Outdoor/Source Water Connection Size FPT (in) Domestic Hot Water Connection Size FPT (in) Maximum Working Pressure (Water Side) Base Unit (PSIG) [kPa] 500 [3445] DHW Option (PSIG) [kPa]... -
Page 10: Dimensions
THW Water-To-Water Series THW Dimensions 1.9” [4.9cm] 2.1” [5.3cm] Water Connections Overall Cabinet Electric Access Plugs Model Source Source Load Load Power Depth Width Height (Outdoor) (Outdoor) (Indoor) (Indoor) Water Out Water In Voltage Voltage Supply Water In Water Out Water In Water Out 26.8... -
Page 11: Electrical Data
ClimateMaster Geothermal Heat Pump Systems Electrical Data Units with DHW Option Compressor ISBP Total Load Source Voltage Min/Max Model Voltage Pump Unit Circuit Fuse Pump Pump Code Voltage Amps HACR 1.07 1.07 22.8 THW010 208-230/60/1 197/254 20.7 1.07 1.07 1.07 23.9 29.1 Standard (No DHW) -
Page 12: Wiring Diagrams
THW Water-To-Water Series THW010 Electrical Wiring Diagram - 230/60/1 96B0108N05 ClimateMaster: Smart. Responsible. Comfortable. - Page 13 ClimateMaster Geothermal Heat Pump Systems THW010 Electrical Wiring Diagram - 230/60/1 96B0108N05 Residential Products Technical Guide...
- Page 14 THW Water-To-Water Series THW010 Electrical Wiring Diagram - 230/60/1 VSFP - 96B0108N06 ClimateMaster: Smart. Responsible. Comfortable.
- Page 15 ClimateMaster Geothermal Heat Pump Systems THW010 Electrical Wiring Diagram - 230/60/1 VSFP - 96B0108N06 Residential Products Technical Guide...
- Page 16 THW Water-To-Water Series Typical Wiring Diagram - THW010 DHW - 96B0108N08 ClimateMaster: Smart. Responsible. Comfortable.
- Page 17 ClimateMaster Geothermal Heat Pump Systems Typical Wiring Diagram - THW010 DHW - 96B0108N08 Residential Products Technical Guide...
- Page 18 THW Water-To-Water Series Typical Wiring Diagram - THW010 DHW + VSFP - 96B0108N09 ClimateMaster: Smart. Responsible. Comfortable.
- Page 19 ClimateMaster Geothermal Heat Pump Systems Typical Wiring Diagram - THW010 DHW + VSFP - 96B0108N09 Residential Products Technical Guide...
-
Page 20: Engineering Guide Specifi Cations
THW Water-To-Water Series Engineering Guide Specifi cations General Electrical The water-source heating units shall be high temperature water-to- CXM Control – A microprocessor-based compressor controller water heat pumps. Units shall be performance rated in accordance shall be provided to monitor and control unit operation. The control with EN 14511-2 or AHRI/ISO/ASHRAE 13256-2, and listed by a shall provide compressor enable, high and low pressure monitoring, recognized safety-testing laboratory or agency, such as ETL. -
Page 21: Accessories & Options
It is expressly understood that unless a statement is specifi cally identifi ed as a warranty, statements made by Climate Master, Inc. a Delaware corporation, (“CM”) or its representatives, relating to CM’s products, whether oral, written or contained in any sales literature, catalog or agreement, are not express warranties and do not form a part of the basis of the bargain, but are merely CM’s opinion or commendation of CM’s products. -
Page 22: Revision History
THW Water-To-Water Series Revision History Date Page # Description 14 Jan., 13 Physical Data Corrected Wire Diagram 27 July, 10 Wire Diagram revision: water-side high pressure switches added Pages 30 Mar, 10 Misc. format, physical data, and electrical data 30 Mar, 10 Decoder Page Decoder Updated 1 Mar, 10...
