Related Manuals for Microlife BP W70 BT
Summary of Contents for Microlife BP W70 BT
- Page 1 BP3KN1-3B Microlife BP W70 BT (BP3KN1-3B) User Manual English IB BP3KN1-3B V4920 EN...
- Page 2 BP3KN1-3B Important Product and Safety Information Follow Instructions for Use. This document provides important product operation and safety information regarding this Blood Pressure Monitor. Please read this document thoroughly before using the device and keep for future reference. This blood pressure monitor is an automatic digital blood pressure measuring device for use by adults on the wrist at home.
- Page 3 When replacing the batteries, ensure all the batteries are replaced simultaneously to avoid battery damage and potential damage to the monitor. Microlife USA does not recommend using rechargeable batteries. ...
- Page 4 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to the product are not approved by Microlife USA and could void the user's authority to operate the equipment under FCC jurisdiction.
- Page 5 BP3KN1-3B encouraged to try to correct the interference by one or more of the following measures: reorient or relocate the receiving antenna, increase the separation between the equipment and receiver, connect the equipment into an outlet on a circuit different from that to which the receiver is connected, consult the dealer or an experienced radio/TV technician for help.
-
Page 6: Table Of Contents
BP3KN1-3B Wrist Blood Pressure Monitor Instruction Manual Table of contents Introduction 1.1. Your automatic wrist blood pressure monitor 1.2. Inflation mode technology How is blood pressure measured? 2.1. What is blood pressure, and why does it fluctuate? 2.2. Measurement guidelines 2.3. -
Page 7: Introduction
BP3KN1-3B 1. Introduction 1.1. Your automatic wrist blood pressure monitor Thank you for purchasing a fully automatic wrist blood pressure monitor. Your monitor is designed to provide fast and reliable digital readings of your pulse, and systolic / diastolic blood pressure using the oscillometric method on your wrist. It offers clinically proven accuracy and has been designed to be user friendly. -
Page 8: How Is Blood Pressure Measured
BP3KN1-3B 2. How is blood pressure measured? 2.1. What is blood pressure, and why does it fluctuate? Your level of blood pressure is determined in the circulatory center of the brain and adjusts to a variety of situations through feedback from the nervous system. To adjust blood pressure, the strength and frequency of the heart (pulse), as well as the width of circulatory blood vessels is altered. -
Page 9: What Can I Do To Change My Blood Pressure
BP3KN1-3B Additional information • If your values are mostly normal under resting conditions but exceptionally high under conditions of physical or psychological stress, it is possible that you are suffering from so-called "labile hypertension." Consult your physician. 2.3. What can I do to change my blood pressure? a). -
Page 10: Components Of Your Blood Pressure Monitor
BP3KN1-3B 3. Components of your blood pressure monitor The illustration shows your blood pressure monitor, consisting of: 1. ON/OFF Button 2. Display 3. M-button (memory) 4. Time Button 5. Battery Compartment 6. Cuff 7. Systolic Value 8. Diastolic Value 9. Pulse Rate 10. -
Page 11: How Do I Get Started
BP3KN1-3B 4. How do I get started? 4.1. Inserting the batteries After you have unpacked your device, insert the batteries. The battery compartment is located on the side of the device. a). Remove the battery cover. To open battery cover: Turn the monitor over, locate the pull on cover and use your finger tip to pull it towards you. -
Page 12: Selecting Heart Level Indicator
BP3KN1-3B all 3 measurements are taken. • Do not remove the cuff between measurements. • If one of the individual measurements was questionable, an additional measurement is automatically taken. 4.3. Selecting Heart Level Indicator Keeping the wrist at the same height level as heart during measurement is one of the most important facts to use a wrist blood pressure monitor. -
Page 13: Setting The User
BP3KN1-3B • If you want to change the date and time, press and hold the time button down for approx. 3 seconds to enter setting menu. Press time button twice to skip MAM mode/ Heart Level Indicator setting until the year number starts to flash. Now you can enter the new values as described above. -
Page 14: Taking A Measurement
BP3KN1-3B accumulated blood to flow away. 5.3. Taking a measurement • Select standard (single measurement) or MAM mode (automatic double measurement): see details in chapter 4.2 • Press the ON/OFF button to start the measurement. • After Heart Level Indicator checked (see details in chapter 4.3), the cuff will now pump up automatically. -
Page 15: Data Memory
BP3KN1-3B at an early stage. 6. Data Memory This model is designed for two users and can store up to 99 blood pressure readings for each user. Select either user 1 or 2 by pressing the time button. Viewing the stored values Press the M-button briefly, when the device is switched off. -
Page 16: Battery Change Indicator
BP3KN1-3B 7. Battery change indicator Low battery When the batteries are approximately ¾ empty the battery symbol will flash as soon as the device is switched on (partly filled battery displayed). Although the device will continue to measure reliably, you should obtain replacement batteries. Flat battery –... -
Page 17: Bluetooth® Functions And Application (App)
BP3KN1-3B ® 8. Bluetooth functions and application (App) This device can be used in conjunction with a smartphone running the «Microlife Connected ® Health+» App. The Bluetooth connection is automatically active after the measurement has been completed. ® Please download the “Microlife Connected Health+” App from Apple’s App Store ®... - Page 18 Indicator error for Heart Level Indicator. Turn off and remove the battery then repeat measurement. It still displayed, please contact your local Microlife-Service. Pulse or cuff The pressure in the cuff is too high (over 299 «HI» pressure too high mmHg) OR the pulse is too high (over 199 beats per minute).
-
Page 19: Safety, Care, Accuracy Test And Disposal
10 seconds. To solve the problem, please visit www.microlife.com/connect. * Please immediately consult your doctor, if this or any other problem occurs repeatedly. If you think the results are unusual, please read through the information in «Section 5.»... - Page 20 BP3KN1-3B Please read this document thoroughly before using the device and keep for future reference. This device may only be used for the purposes described in these instructions. The manufacturer cannot be held liable for damage caused by incorrect application. ...
-
Page 21: Guarantee
Carefully remove any marks on the cuff with a damp cloth and mild detergent. Accuracy test We recommend this device is tested for accuracy every 2 years or after mechanical impact (e.g. being dropped). Please contact your local Microlife-Service to arrange the test (see foreword). 11. Guarantee... -
Page 22: Technical Specifications
Atmospheric pressure range：…70KPa -106KPa Accessories included：………user manual，Storage Box，Gift box，BP diary，2xAAA Batteries Technical alterations reserved. 13. How to contact us Distributed by: Microlife USA, Inc. 1617 Gulf to Bay Blvd. Clearwater, FL 33755 Toll Free Help Line: 1-800-568-4147 Email: custserv@microlifeusa.com www.microlifeusa.com...
