Sices DST4602 Evolution User Manual page 7

Pushbuttons Function
Vertical scrolling buttons. These buttons let you select the multifunctional
display mode.
In PROGRAM and HISTORY LOGS mode you can scroll the menus and the
variables/settings. You can increase/decrease the value of the variable to
change the settings. Used in combination with the SHIFT
scroll through the menu ten entries at a time or increase/decrease the variables
ten units at a time. During the keyboard regulation phase you can increase or
decrease the engine speed (if set to synchronized) or the power supplied (if in
UP/DOWN
power mode).
Lets you enter the PROGRAMMING mode and open submenus, change a
variable, and confirm the operation. Furthermore, you can enable the HISTORY
LOGS function and open the selected log, "acknowledge" any EEPROM errors
at power-up, in the manual synchronization and power setting phase, and enable
ENTER
keyboard regulation.
In programming mode, it cancels the changes made to a variable value, brings
up the previous menu level, or exits programming mode. If it is pressed for at
least two seconds in any menu, you exit the programming mode retaining the
current menu position for further programming access. Use the SHIFT
button to control the fuel pump manually. Used with the ACK/TEST
EXIT
it resets the partial counters selected with the ENTER
the default programming parameters (in the version with CANBUS, it also lets
you force the exit BUS OFF mode). When used during the keyboard regulation
function, it aborts the function.
Used to command the General Circuit Breaker (GCB) or changeover. The
actual function depends also on the plant configuration. In parallel mode with at
least one other source powering the BUS, if the button is pressed it activates
the fast unload ramp before the circuit breaker opens.
GCB
In case no ramp is needed, simply keep it pressed for a few seconds until the
GCB is opened.
Used to command the Mains Circuit Breaker (MCB) or the changeover. The
actual function depends also on the plant configuration.
MCB
Used to acknowledge any kind of alarm and to silence the horn. In the case of a
malfunction, pressing this button deactivates the horn; pressing the button again
acknowledges the anomaly, cancelling any inactive warnings. In conjunction with
the START
ACK/TEST
activate/deactivate the TEST mode. Used with the EXIT
counters and reloads the default programming parameters (in the version with
CANBUS, it also lets you force the exit from BUS OFF mode).
, button, with the selector in AUTO mode, it can be used to
button you can
, button,
button and reloads
button, it resets the
DST4602 User's Manual
7
